Schneider TSXRKY6 Non-Extendable Rack

Brand:Schneider PLC
Item No.:TSXRKY6
Product Origin:France
Product Dimensions:210 × 180 × 60 mm
Product Weight:1.8kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

TSXRKY6 - 1TSXRKY6 - 2TSXRKY6 - 3TSXRKY6 - 4TSXRKY6 5TSXRKY6 6

Robust Structural Base for PLC System Architecture

The Schneider TSXRKY6 Non‑Extendable Rack serves as a durable mechanical backbone for mounting and organizing programmable logic controller (PLC) modules, power supplies, communication cards, and I/O interfaces. Designed for industrial control panels, this fixed‑length rack enables orderly installation of automation components, simplifying cabinet layout, airflow management, and wiring runs.

Its non‑extendable form factor makes it a solid choice for control systems with a defined set of modules where future expansion isn’t anticipated or where space‑efficient design is prioritized.

Technical Specifications

ParameterSpecification
Product TypeNon‑Extendable Rack (Backplane Chassis)
Model NumberTSXRKY6
Compatible SystemsSchneider Electric Modicon/TSX & Premium
Rack TypeFixed Length, Non‑Extendable
Slot Count6 Slots
Slot PitchStandard PLC module pitch
Power BusIntegrated backplane power rails
Communication BusIntegrated data bus for CPU/I/O communication
MaterialIndustrial‑grade steel
Surface FinishPowder‑coated
MountingPanel or enclosure wall mounting
Operating Temperature‑10°C to +60°C
Storage Temperature‑40°C to +85°C
Dimensions (HxWxD)Approx. 210 × 180 × 60 mm
WeightApprox. 1.8 kg


Typical Applications

The TSXRKY6 Non‑Extendable Rack is widely used wherever structured PLC installation is required, especially in compact cabinets or designated automation enclosures. Typical use cases include:

  • Machine Control Panels: Mounting CPUs, I/O modules, power supplies, and communication cards in a neat, accessible layout.

  • OEM Equipment: Embedding PLC systems into machinery where space and simplicity are priorities.

  • Distributed Control Cabinets: Serving as a fixed rack base for standardized control system stations.

  • Process Skids: Providing rigid mechanical support for modular automation units transported or deployed on skids.

This rack is ideal in environments where the control system design is stable and modules are planned to remain consistent over the life of the equipment.


Key Advantages and Features

  • Simplified Module Integration: Pre‑defined rack spacing and integrated bus rails enable quick and error‑free module installation.

  • Sturdy Construction: Industrial‑grade materials and powder‑coated finish ensure resistance to vibration and mechanical stress.

  • Efficient Wiring Management: Rack design accommodates orderly wiring routing and labeling for easy maintenance.

  • Space‑Efficient Design: Fixed six‑slot format fits compact control cabinets without unnecessary bulk.

  • Reliable Bus Connectivity: Integrated power and data buses ensure dependable communication between CPU and I/O modules.

Whether in manufacturing, process automation, utilities, or machine building, this chassis provides a stable foundation for critical automation hardware.


Technical FAQs

1. What is the purpose of the TSXRKY6 rack?
It provides a secure mechanical base and integrated backplane for mounting PLC modules.

2. How many module slots does it support?
Six standard PLC slots.

3. Can it support a CPU and I/O cards together?
Yes, the integrated backplane supports CPU, communication, and I/O modules.

4. Is the rack extendable?
No, it has a fixed, non‑extendable design.

5. Where is it typically mounted?
On control cabinet panels or enclosure walls.

6. What materials are used in construction?
Industrial‑grade steel with a protective finish.

7. Does it include power rails?
Yes, it features integrated power bus rails for connected modules.

8. Can it be used with Premium and TSX systems?
Yes, it’s compatible with a range of Schneider PLC module formats.

9. What environments is it designed for?
Industrial temperature ranges and factory‑floor conditions.

10. How does it help with wiring organization?
Its design supports orderly cable routing and labeling across mounted modules.
