Introduction
The Ovation 1X00416H01 Power Supply is a dedicated industrial power conversion module designed for the Emerson Ovation Distributed Control System (DCS). Serving as a core component of Ovation I/O cabinets and controller racks, this power supply delivers regulated DC voltage essential for stable system operation, signal processing, and control logic execution.
With a compact yet robust construction suitable for demanding plant environments, the 1X00416H01 ensures dependable performance across critical applications such as power generation, process automation, and large‑scale infrastructure control. Its engineering focuses on reliability, electrical protection, and seamless integration into the Ovation ecosystem.
Technical Specifications
| Specification | Details |
|---|
| Model | 1X00416H01 |
| Manufacturer | Emerson Ovation |
| Product Type | Power Supply |
| System Platform | Ovation Distributed Control System |
| Output Voltage | Regulated 24 V DC |
| Output Current | System‑dependent rating for I/O and controller power |
| Input Voltage | Typically 120–240 VAC (50/60 Hz) |
| Input Frequency | 50/60 Hz |
| Power Conversion | AC to DC |
| Protection | Overload and short‑circuit protection |
| Mounting | Rack‑mounted or chassis‑integrated installation |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | ‑40 °C to +85 °C |
| Relative Humidity | 5–95 % non‑condensing |
| Enclosure Rating | Industrial grade |
| Dimensions | Standard Ovation rack power supply form factor |
| Weight | Approx. 0.8–2.5 kg (system configuration dependent) |
Applications
Distributed Control System Power Distribution
Supplies DC voltage to Ovation I/O modules, controllers, and associated electronics within distributed control cabinets.
Power Generation Control Panels
Used in steam, gas, and combined cycle power plants to deliver stable power to turbine, boiler, and generator control systems.
Refinery and Petrochemical Automation
Provides reliable DC power for process controllers and I/O modules in complex process automation environments.
Water & Wastewater Control Systems
Ensures continuous and stable power for monitoring and control systems in municipal and industrial water facilities.
Infrastructure and Utility Automation
Supports Ovation control systems used in utility substations, industrial automation hubs, and large‑scale infrastructure facilities.
Advantages
Regulated Output for Stable Control
Delivers consistent 24 V DC output to support Ovation controllers, I/O modules, and associated electronics under varying load conditions.
Built‑In Protection Mechanisms
Features overload and short‑circuit protection to help safeguard both the power supply and connected modules.
Industrial‑Grade Reliability
Designed to operate continuously in typical industrial environments with broad temperature and humidity tolerance.
Seamless Ovation Integration
Fits into Ovation racks and chassis with standardized mounting and connections, simplifying installation and maintenance.
Efficient Power Conversion
Converts AC mains power to stable DC with high efficiency to reduce heat generation and prolong module life.
Technical FAQs
1. What is the primary function of the 1X00416H01 power supply?
It provides regulated DC power to the Ovation Distributed Control System racks and modules.
2. What output voltage does this power supply deliver?
The module outputs a regulated 24 V DC supply.
3. What input power does it accept?
It accepts standard AC mains voltages between approximately 120 VAC and 240 VAC at 50/60 Hz.
4. Where is this power supply installed?
It mounts within the Ovation I/O rack or control chassis where it feeds DC power to system modules.
5. What protection features are included?
It includes overload and short‑circuit protection to help protect connected equipment.
6. Can it operate in harsh environments?
Yes — it is designed for continuous operation in industrial settings with broad temperature and humidity tolerance.
7. Is it suitable for power generation control systems?
Yes — it is commonly used in power plant control cabinets to support turbine and plant system automation.
8. What industries frequently use this module?
Power generation, chemical processing, water treatment, and utility automation systems.
9. How does regulated DC benefit automation systems?
Regulated DC ensures stable, predictable voltage for sensitive control electronics, reducing operational errors.
10. Is this power supply compatible with other Ovation modules?
Yes — it is designed specifically for Emerson Ovation Distributed Control System racks and compatible I/O modules.
