Introduction
The Ovation 1X00797H01L Power Module Unit is an essential power supply component designed specifically for the Emerson Ovation Distributed Control System (DCS). It delivers stable and regulated DC power to Ovation system racks, control modules, and distributed I/O assemblies, ensuring reliable performance across real‑time process control applications. Built for continuous industrial operation, this power module supports consistent system behavior and helps maintain uptime in demanding environments.
The 1X00797H01L is engineered with robust electrical protections and efficient power conversion characteristics, making it suitable for power generation facilities, process plants, utility operations, and infrastructure automation systems where dependable control system power is critical.
Technical Specifications
| Specification | Details |
|---|
| Model | 1X00797H01L |
| Manufacturer | Emerson Ovation |
| Module Type | Power Module Unit |
| System Platform | Ovation Distributed Control System |
| Output Voltage | 24 V DC (regulated) |
| Output Current | Rack‑dependent rated current (configurable per architecture) |
| Input Voltage | 100–240 VAC, 50/60 Hz (typical) |
| Input Protection | Surge and overvoltage conditioning |
| Power Conversion | AC to regulated DC |
| Efficiency | High conversion efficiency for stable DC output |
| Protection Features | Overload protection, short‑circuit protection |
| Mounting | Integrated within Ovation DCS rack/enclosure |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | ‑40 °C to +85 °C |
| Relative Humidity | 5–95 % (non‑condensing) |
| Enclosure Rating | Industrial grade |
| Dimensions | Standard Ovation rack power supply form factor |
| Weight | Approx. 1.0–3.0 kg (configuration dependent) |
Applications
Distributed Control Racks
Provides regulated DC power to Ovation I/O and controller modules within distributed control cabinets.
Power Generation Plants
Used in thermal, hydroelectric, and combined cycle plants to ensure stable power for automation systems.
Process Automation Systems
Supports critical control system components in chemical, petrochemical, and industrial process facilities.
Water and Wastewater Treatment
Supplies control electronics in treatment plants where continuous process monitoring and regulation are required.
Utility and Infrastructure Controls
Enables robust power delivery to Ovation systems in utility substations and large infrastructure automation installations.
Applications
Distributed Control Racks
Provides regulated DC power to Ovation I/O and controller modules within distributed control cabinets.
Power Generation Plants
Used in thermal, hydroelectric, and combined cycle plants to ensure stable power for automation systems.
Process Automation Systems
Supports critical control system components in chemical, petrochemical, and industrial process facilities.
Water and Wastewater Treatment
Supplies control electronics in treatment plants where continuous process monitoring and regulation are required.
Utility and Infrastructure Controls
Enables robust power delivery to Ovation systems in utility substations and large infrastructure automation installations.
Technical FAQs
1. What is the function of the 1X00797H01L Power Module Unit?
It supplies regulated DC power to Ovation control system racks and I/O modules to support continuous operation.
2. What output voltage does this power module deliver?
It typically delivers 24 V DC for system power distribution.
3. What input power range is supported?
It accepts standard AC input voltages between approximately 100 VAC and 240 VAC at 50/60 Hz.
4. How is this module mounted?
The module is installed within the Ovation DCS rack chassis as part of the system’s power distribution design.
5. What protection features does it include?
It includes built‑in overload and short‑circuit protections to safeguard the power supply and connected modules.
6. What environments can this module operate in?
Rated for industrial environments between 0 °C and 60 °C with non‑condensing humidity levels.
7. Can it support multiple modules in a rack?
Yes — it is designed to supply power to multiple Ovation I/O and controller modules within a system rack.
8. Why is regulated DC important for control systems?
Regulated DC ensures stable voltage for sensitive control electronics, reducing risk of errors and improving reliability.
9. What industries commonly use this power module?
Common industries include power generation, chemical processing, water treatment, and utility automation.
10. Is maintenance required regularly?
Regular system checks and rack inspection help ensure ongoing performance, though the power module itself is designed for long‑term operation.
