Product Overview
The Woodward 5501-470 CPU Module is a high-performance central processing component for industrial and engine control systems. It manages real-time control, data acquisition, and communication with distributed I/O modules, enabling precise, reliable, and efficient operation.
With a robust, compact design, it integrates easily into control cabinets or industrial racks, providing continuous, reliable processing in demanding environments. This module is essential for applications requiring accurate, high-speed, and fault-tolerant control.
Technical Specifications
| Parameter | Specification |
|---|
| Product Model | 5501-470 |
| Product Type | CPU Module |
| Manufacturer | Woodward |
| Functional Role | Real-Time Processing and Control for Industrial Systems |
| System Compatibility | Woodward Control Units and Remote I/O Modules |
| Installation Type | Control Cabinet / Industrial Rack |
| Dimensions | 260 × 180 × 50 mm |
| Weight | 1.1 kg (2.43 lb) |
Industrial Control and Real-Time Processing Applications
The Woodward 5501-470 CPU Module is the central processing unit for Woodward control systems, designed to execute real-time control, data acquisition, and signal processing for industrial automation, engine, and turbine control applications. It coordinates communication between peripheral modules, field devices, and supervisory systems to ensure accurate, reliable, and timely operation.
This module is critical for applications requiring high-speed computation, deterministic control, and integration with distributed control networks.
Typical applications include:
-
Real-time control of turbines, generators, and engines
-
Data acquisition and processing from remote I/O modules
-
Execution of control logic, alarms, and interlocks in industrial systems
-
Integration with monitoring and diagnostics for predictive maintenance
-
Centralized coordination of distributed control systems
Its robust design ensures stable operation under harsh industrial conditions.
Key Advantages
High-Performance Processing
Executes complex control algorithms and signal processing with minimal latency.
Seamless System Integration
Communicates efficiently with remote I/O modules and supervisory systems.
Industrial-Grade Reliability
Built for continuous operation in electrically noisy and harsh environments.
Supports Redundant Configurations
Can be deployed in dual-CPU or TMR configurations for critical applications.
Compact Yet Durable Design
Optimized for installation in control cabinets while maintaining operational stability.
Technical FAQs
1. What is the main function of the 5501-470 CPU Module?
It serves as the central processing unit for executing real-time control, data acquisition, and communication tasks.
2. Can it handle real-time industrial control applications?
Yes, it is designed for deterministic, high-speed processing suitable for turbine and engine control.
3. Which systems is it compatible with?
Woodward control systems and associated peripheral I/O modules.
4. Does it support remote I/O integration?
Yes, it can acquire and process data from multiple remote I/O modules.
5. Can it operate continuously in harsh environments?
Yes, it is engineered for long-term operation under industrial conditions.
6. How does it improve system reliability?
Supports redundant CPU configurations and ensures stable processing under load.
7. Where is the module installed?
Inside control cabinets or industrial racks as the main control processor.
8. What types of tasks does it execute?
Control logic, real-time process monitoring, alarms, interlocks, and diagnostics.
9. Is it suitable for safety-critical applications?
Yes, it is suitable for industrial systems requiring high reliability and precision.
10. Why is a dedicated CPU module important?
It centralizes processing, coordinates peripheral devices, and ensures precise timing and control for optimal system performance.
