Introduction
The Schneider TSXP572623 Double Format PL7 Processor is a robust central processing unit engineered for the Modicon Premium automation platform. Built for demanding industrial applications, this processor delivers reliable logic execution, flexible communication capabilities, and broad I/O handling capacity. Designed around Schneider’s PL7 programming environment, it supports structured, scalable automation projects and is a dependable choice for mid‑to‑large‑scale control systems.
The TSXP572623 combines strong processing performance with durable industrial design, ensuring stable operation in continuous production environments such as manufacturing lines, process automation systems, and distributed control architectures.
Technical Specifications
| Specification | Details |
|---|
| Model | TSXP572623 |
| Manufacturer | Schneider Electric |
| Module Type | Double Format PL7 Processor |
| Automation Platform | Modicon Premium |
| Programming Software | PL7 / Unity Pro compatible |
| Discrete I/O Capacity | Up to 2048 points |
| Analog I/O Capacity | Up to 256 points |
| Processing Performance | Balanced industrial execution |
| Memory | On‑board program and data memory |
| Comm Interfaces | Ethernet (10/100 Mbps), serial ports |
| Optional Comm Modules | Up to 4 expansion modules |
| Status Indicators | LEDs for RUN, ERR, I/O, COMM |
| Slot Format | Double module format |
| Power Consumption | Standard DC supply per rack |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | ‑25°C to 70°C |
| Relative Humidity | 5–95% non‑condensing |
| Protection Rating | IP20 |
| Weight | Approx. 0.68 kg |
| Mounting | Modicon Premium rack |
Applications
Manufacturing Automation
Ideal for controlling logic sequences, machine motion, and coordinated processes on production lines and assembly systems.
Process Control Systems
Supports continuous monitoring and regulation of chemical, energy, or material processing operations requiring reliable execution and large I/O support.
Distributed Control Architectures
Integrates seamlessly with distributed remote I/O networks and communication modules to deliver flexible and scalable automation systems.
Machine Builder Solutions
Machine OEMs leverage the TSXP572623 for its execution performance and modular expansion, allowing customization and extended functionality in complex equipment.
Plant‑Wide Control Integration
Provides connectivity to higher‑level systems such as SCADA and MES via standard communication interfaces and optional fieldbus modules.
Advantages
Balanced Performance and Scalability
Delivers a strong balance of logic throughput and input/output capacity without excessive system cost or complexity.
PL7 Programming Compatibility
Supports Schneider’s PL7 environment, enabling structured coding techniques, reusable program components, and streamlined development workflows.
Flexible Connectivity
Standard Ethernet and serial interfaces, along with support for multiple optional communication modules, enhance network flexibility.
Industrial‑Ready Design
Engineered to withstand typical factory conditions with a broad temperature range and resistance to humidity and electrical noise.
Extensive I/O Support
Capable of managing large I/O counts and diverse field device interfaces, which simplifies system design and expansion.
Technical FAQs
1. What does the TSXP572623 processor do?
It is a central processing unit for Modicon Premium PLC systems, executing control logic and interfacing with field devices.
2. Which programming software is supported?
It works with PL7 and is compatible with Schneider’s Unity Pro programming environments.
3. How many I/O points can it handle?
It supports up to 2048 discrete and 256 analog I/O points.
4. What communication options are available?
Standard Ethernet (10/100 Mbps) and serial ports are included, with expansion possible via optional communication modules.
5. How many optional modules can be added?
Up to four communication expansion modules are supported.
6. What slot format does it use?
A double module format within a Modicon Premium rack.
7. What environmental conditions can it withstand?
Rated for 0°C to 60°C and up to 95% non‑condensing humidity.
8. Is the processor suitable for large automation systems?
Yes — its I/O capacity and communication flexibility make it suitable for mid‑to‑large automation systems.
9. Can it integrate with SCADA systems?
Yes — Ethernet and optional fieldbus communication allow integration with SCADA, MES, and other networked systems.
10. Does it have diagnostic indicators?
Yes — LEDs provide status for RUN, ERROR, I/O activity, and communication.
