Product Overview
The Ovation 1C31164G01 RTD Input Module is a high-precision temperature acquisition component for industrial applications. By converting RTD resistance signals into accurate digital temperature data, it enables Ovation distributed control systems to perform real-time monitoring, trending, and control.
The module’s compatibility with multiple RTD types and wiring configurations makes it highly versatile. Its rugged industrial design ensures dependable performance in demanding environments, making it essential for accurate and continuous temperature monitoring in critical processes.
Technical Specifications
| Parameter | Specification |
|---|
| Product Model | 1C31164G01 |
| Product Type | RTD Input Module |
| Manufacturer | Ovation |
| Functional Role | Temperature Measurement via RTD Inputs |
| System Compatibility | Ovation Distributed Control Systems |
| Installation Type | Control Cabinet / I/O Rack |
| Dimensions | 120 × 90 × 60 mm |
| Weight | 0.5 kg (1.102 lb) |
High-Accuracy Temperature Monitoring for Industrial Processes
The Ovation 1C31164G01 RTD Input Module is designed for precise acquisition of temperature data from Resistance Temperature Detectors (RTDs) within Ovation distributed control systems (DCS). Accurate temperature monitoring is critical in industries such as power generation, chemical processing, and manufacturing, where process stability and safety depend on reliable thermal measurement.
This module converts resistance measurements from RTDs into calibrated digital temperature values, allowing the control system to monitor, trend, and respond to temperature changes in real time.
Typical applications include:
-
Boiler, turbine, and generator temperature monitoring in power plants
-
Temperature control in chemical, petrochemical, and food processing plants
-
Thermal process monitoring in industrial manufacturing lines
-
Integration of multiple RTDs into Ovation DCS for centralized monitoring
-
Safety and alarm systems requiring accurate thermal inputs
Its robust and precise measurements ensure operational efficiency and process safety.
Key Advantages
High-Precision Temperature Acquisition
Accurately converts RTD resistance to temperature for reliable measurement.
Real-Time DCS Integration
Provides immediate, calibrated temperature readings to Ovation control systems.
Supports Multiple RTD Configurations
Compatible with 2-, 3-, and 4-wire RTDs for flexible installations.
Industrial-Grade Reliability
Built to endure harsh environments and electrical noise without performance degradation.
Space-Efficient Design
Compact form factor suitable for installation in control cabinets and I/O racks.
Technical FAQs
1. What is the main function of the 1C31164G01 module?
To acquire RTD signals and convert them into accurate temperature readings for the DCS.
2. Which RTD types are supported?
Platinum RTDs, including PT100, PT500, and PT1000.
3. How is the temperature data communicated to the control system?
The module converts resistance into calibrated digital signals compatible with Ovation DCS.
4. Can it support multiple RTD inputs?
Yes, depending on system configuration, multiple RTD channels can be connected.
5. Is it suitable for noisy industrial environments?
Yes, it includes signal conditioning and shielding for reliable operation.
6. Where is the module installed?
Inside control cabinets or I/O racks within Ovation DCS.
7. How does it support process safety?
By providing accurate temperature readings for alarms, interlocks, and control logic.
8. Can it provide continuous monitoring?
Yes, it delivers real-time temperature data continuously.
9. Which industries commonly use this module?
Power generation, chemical, petrochemical, food processing, and industrial automation.
10. Why is RTD input accuracy important?
Precise measurements ensure safe operation, energy efficiency, and consistent product quality.
