Schneider TSXCTZ1B Encoder Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Schneider TSXCTZ1B Encoder Module

Name: Schneider TSXCTZ1B Encoder Module
Brand: Schneider PLC
SKU: 6059
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Schneider PLC
Item No.:TSXCTZ1B
Product Origin:France
Product Dimensions:6.0 × 6.0 × 9.5 cm
Product Weight:0.55 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The TSXCTZ1B Encoder Module is a precision industrial encoder designed for seamless integration with Schneider Electric Modicon Premium PLC systems. Engineered for high-accuracy motion and position monitoring, this module provides reliable feedback for rotary and linear applications. Its robust construction ensures consistent performance in demanding industrial environments, making it ideal for machine automation, robotics, packaging lines, and conveyor systems. With the TSXCTZ1B, you get precision, durability, and adaptability all in a compact form factor.

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Product Type	Incremental Encoder Module
Platform	Modicon Premium Automation
Output Type	Digital incremental signals (A, B, Z channels)
Resolution	1,024 pulses per revolution (PPR)
Output Voltage	5 V DC or 24 V DC selectable
Maximum Frequency	Up to 100 kHz input signals
Shaft Type	Hollow or solid shaft options
Bearings	High-precision ball bearings for smooth rotation
Operating Temperature	0 °C to 60 °C
Storage Temperature	‑25 °C to 70 °C
Humidity	5 %–95 % (non-condensing)
Dimensions (approx.)	6.0 × 6.0 × 9.5 cm (2.36″×2.36″×3.74″)
Weight	~0.55 kg (1.21 lb)

Applications

The TSXCTZ1B Encoder Module is perfect for applications where accurate position tracking and motion feedback are critical:

Rotary motion detection in industrial machinery
Conveyor speed and position monitoring
Robotic arm position control and automation
Packaging machine feedback loops
Integration with Modicon Premium PLCs for precision automation

Its compact and rugged design allows installation in harsh industrial environments while maintaining high reliability.

Advantages

High Precision: Provides up to 1,024 pulses per revolution for accurate motion tracking
High-Speed Performance: Handles signals up to 100 kHz for rapid motion detection
Versatile Output: Supports both 5 V DC and 24 V DC for flexible integration
Durable Design: High-quality bearings and solid construction ensure long service life
Compact Form Factor: Fits easily into PLC racks and control cabinets without taking up excessive space

Technical FAQs

What type of signals does TSXCTZ1B output?
- Digital incremental signals (A, B, Z channels).
What is the maximum resolution of this encoder?
- 1,024 pulses per revolution (PPR).
Can it handle high-speed rotation?
- Yes, it supports up to 100 kHz signal frequency.
Is the module compatible with both hollow and solid shafts?
- Yes, it supports both types of shafts.
What operating temperature range is supported?
- 0 °C to 60 °C for industrial operation.
Can it be used in high-humidity environments?
- Yes, it operates reliably from 5 %–95 % relative humidity (non-condensing).
What output voltages are supported?
- Selectable 5 V DC or 24 V DC outputs.
Are the bearings maintenance-free?
- Yes, high-precision ball bearings provide long-lasting performance.
Can it be integrated with existing Modicon Premium PLC systems?
- Yes, it is designed for seamless integration.
Is the module suitable for robotics applications?
- Absolutely, it provides accurate position feedback for robotic systems.
