Product Overview
The Woodward CSC3HUWB2 SEG Controller Module is an industrial‑grade embedded controller designed to manage and protect SEG (Speed, Emergency, Governor) functions in generator and engine systems. As part of Woodward’s control solutions family, this module delivers reliable regulation of speed and emergency shutdown, precise engine governance, and seamless integration with broader control architectures. Its robust design and configurable logic capabilities make it suitable for heavy‑duty power generation, marine propulsion, and large industrial engine applications.
Engineers rely on this controller module to ensure stable engine operation, accurate speed regulation under varying loads, and fast protective responses when conditions exceed preconfigured thresholds. Compact, rugged, and flexible, the CSC3HUWB2 supports both standalone and networked control schemes in demanding industrial environments.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Woodward |
| Model | CSC3HUWB2 |
| Product Type | SEG Controller Module |
| Series | SEG Control Solutions |
| Operating Voltage | 12 / 24 V DC |
| Controller Logic | Embedded control with configurable parameters |
| Digital Inputs | Multiple configurable digital inputs |
| Analog Inputs | Multiple isolated analog inputs |
| Speed Control Output | PWM or analog governor control outputs |
| Emergency Shutdown | Dedicated emergency shutdown inputs/outputs |
| Communication | CAN/LIN/Serial interfaces (configurable) |
| Operating Temperature | −20 °C to +70 °C |
| Storage Temperature | −40 °C to +85 °C |
| Mounting Method | Panel / DIN options |
| Dimensions | 125 mm × 90 mm × 45 mm |
| Weight | Approx. 0.24 kg |
| Protection | Rugged industrial design |
Application Scenarios
The CSC3HUWB2 SEG controller module is optimized for systems requiring robust speed governance and emergency shutdown logic.
Industrial Generator Sets
Controls engine speed and manages emergency shutdown signals to protect generator units under fault conditions.
Marine Propulsion Systems
Manages governor control and protective shutdown in marine diesel engines where precise speed regulation is critical.
Oil & Gas Power Units
Used in critical power modules for drilling rigs and remote generator installations where reliability is vital.
Heavy‑Duty Engine Control
Integrates into industrial engine control panels for pumps, compressors, and turbine regulation.
Key Advantages
Precise Speed Regulation
Delivers smooth and accurate governor control under varying load conditions to maximize efficiency and minimize wear.
Fast Emergency Response
Dedicated emergency shutdown logic ensures rapid protective action during abnormal engine events.
Flexible Communication
Supports multiple interface protocols (CAN/LIN/serial) for integration with broader control and monitoring systems.
Configurable Logic Capabilities
Allows engineers to tailor control response curves, shutdown thresholds, and governor profiles.
Rugged Industrial Design
Built to withstand harsh environments, with a wide operating temperature range and industrial mounting options.
Key Advantages
Precise Speed Regulation
Delivers smooth and accurate governor control under varying load conditions to maximize efficiency and minimize wear.
Fast Emergency Response
Dedicated emergency shutdown logic ensures rapid protective action during abnormal engine events.
Flexible Communication
Supports multiple interface protocols (CAN/LIN/serial) for integration with broader control and monitoring systems.
Configurable Logic Capabilities
Allows engineers to tailor control response curves, shutdown thresholds, and governor profiles.
Rugged Industrial Design
Built to withstand harsh environments, with a wide operating temperature range and industrial mounting options.
