Product Introduction
The Schneider Electric LXM32AD30N4 Motion Servo Drive is a powerful and versatile motion control drive engineered for precision servo motor applications in automated systems. As part of the Lexium 32 servo drive family, this model delivers smooth torque control, high dynamic response, and robust performance across a wide range of industrial applications. Its intuitive setup, built‑in safety features, and support for advanced positioning make it a preferred choice for both new designs and system upgrades.
Designed to work seamlessly with Schneider Electric’s motion controllers, PLCs, and human‑machine interfaces, the LXM32AD30N4 brings high‑accuracy motion control to robotics, packaging machines, CNC systems, and other precision automation tasks. Built for reliability, scalability, and easy integration, it enhances overall system responsiveness and productivity.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Schneider Electric |
| Model Number | LXM32AD30N4 |
| Module Type | Motion Servo Drive |
| Product Family | Lexium 32 |
| Rated Power | 3.0 kW |
| Current Rating (RMS) | 10 A |
| Supply Voltage | 380–480 V AC (3‑phase) |
| Control Methods | Torque, Speed, Position Control |
| Feedback Compatibility | Incremental Encoders, Resolver |
| Control Interface | Fieldbus (EtherCAT / CANopen optional) |
| Auxiliary Supply | 24 V DC |
| Protection Rating | IP20 |
| Cooling Method | Convection / Forced‑Air (as required) |
| Mounting | DIN Rail or Panel Mount (depending on variant) |
| Dimensions (W × H × D) | 90 × 180 × 155 mm |
| Weight | Approx. 2.6 kg |
| Operating Temperature | 0°C to 50°C |
| Safety Standards | CE, UL, IEC |
Industrial Applications
Robotics & Precision Positioning
Delivering accurate torque and position control, the LXM32AD30N4 is suited for robotic arms, automated handling systems, and pick‑and‑place operations where tight motion control is demanded.
Packaging & Material Handling
In high‑speed packaging lines and conveyor systems, this servo drive ensures smooth motion transitions and consistent operation even under dynamic loads.
CNC Machines & Tooling
For machining centers and CNC applications, it provides the high‑frequency response and motion accuracy necessary for precision tooling and surface finishes.
Printing & Labeling Systems
The drive supports rapid acceleration and deceleration cycles, enhancing throughput in printing presses, labeling lines, and registration control systems.
Key Advantages
High‑Performance Motion Control
With advanced torque, speed, and position regulation, this drive delivers precise and repeatable motion for demanding applications.
Flexible Feedback Support
Compatible with both incremental encoders and resolver feedback devices, enabling integration with a wide range of servo motors.
Robust Industrial Design
Built to withstand industrial environments, its IP20 rating and thermal protection ensure reliable operation over long duty cycles.
Scalable Connectivity
Optional fieldbus interfaces, including EtherCAT or CANopen, integrate seamlessly with modern PLC and motion control architectures.
Intuitive Setup and Tuning
User‑friendly configuration tools allow fast commissioning and motion tuning, reducing installation and commissioning time.
Technical FAQs
1. What power range does the LXM32AD30N4 support?
It is a 3.0 kW servo drive designed for medium to high performance motion systems.
2. What feedback devices are supported?
The drive supports both incremental encoders and resolver feedback for motor feedback.
3. What control modes are available?
Torque, speed, and position control modes are supported for flexible motion strategies.
4. What supply voltage is required?
It operates on 380–480 V AC three‑phase supply voltage.
5. Can this drive work with various fieldbus networks?
Yes — optional EtherCAT or CANopen interfaces allow integration into distributed control networks.
6. What is the typical operating temperature range?
The drive is designed to operate reliably between 0°C and 50°C.
7. Is this drive suitable for high‑speed applications?
Yes — its dynamic control algorithms and high sampling rates support fast motion profiles.
8. What protection class does the unit have?
The unit carries an IP20 protection rating for installation inside control cabinets.
9. Can the drive be mounted in compact cabinets?
Yes — its form factor supports DIN‑rail or panel mounting depending on system design.
10. Is diagnostic information available during operation?
Most configurations provide status LEDs and diagnostic registers for real‑time monitoring via controller interfaces.
