Product Introduction
The Schneider Electric LMC058LF42 Motion Controller is a high-performance motion control unit engineered for industrial automation, designed to execute coordinated, synchronized, and interpolated motion tasks within machine and motion-centric applications. As part of Schneider’s Modicon LMC058 controller family, it delivers advanced motion logic, fast I/O, and multiple communication interfaces in a compact form factor—ideal for complex motion sequences, high-speed counting, and synchronized multi-axis motion control.
Built to meet the demands of modern manufacturing, packaging, and robotics systems, this controller combines robust processing performance with versatile communication options such as CANopen Master, CANmotion Master, Ethernet, and serial interfaces. It helps streamline system architecture while ensuring precise motion execution across coordinated devices.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Schneider Electric |
| Model Number | LMC058LF42 |
| Module Type | Motion Controller |
| Product Family | Modicon LMC058 |
| I/O Configuration | 42 Discrete I/O |
| High-Speed Counters | 8 @ 200 kHz |
| Controller Memory | 128 MB Flash, 64 MB RAM |
| Battery | 3 V CR2477M Lithium |
| Communication Interfaces | Ethernet, RS232/RS485, CANopen Master, CANmotion Master, USB-A, USB-Mini |
| LED Status Indicators | RUN/MS, BATTERY, APP0, APP1, plus comm port status LEDs |
| Supply Voltage | 24 V DC |
| Mounting | DIN Rail |
| Protection Rating | IP20 |
| Dimensions (W × D × H) | 175 × 85 × 99 mm |
| Weight | Approx. 0.55 kg |
| Operating Temperature | 0 °C to 60 °C |
| Certifications | CE, UL 508, IEC 61131-2, CSA |
Industrial Applications
Multi-Axis Machine Control
The controller excels in systems requiring highly coordinated motion across multiple axes, such as robotics, gantries, and complex servo drives.
Packaging and Material Handling
Precise motion sequencing and high-speed counting support tight packaging tolerances and fast production rates.
Process and Conveyor Systems
In manufacturing lines, the unit integrates seamlessly with drives and sensors, enabling efficient real-time motion control and system synchronization.
OEM Machinery Automation
Original equipment manufacturers benefit from the controller’s flexibility and communication options when delivering bespoke motion control solutions.
Key Advantages
Integrated Motion Capabilities
Delivers advanced multi-axis motion control with synchronized execution and high-speed counting built-in—reducing the need for distributed motion modules.
Versatile Communication Suite
Supports Ethernet, CANopen, CANmotion Master, USB, and RS-232/485, enabling robust connectivity with drives, HMIs, and networked field devices.
Robust I/O Performance
With 42 discrete I/O points and 200 kHz high-speed counters, it handles fast events and complex digital interactions without compromise.
Compact Industrial Form Factor
DIN-rail mountable and IP20 rated, the controller integrates cleanly into automation cabinets while maintaining industrial durability.
Seamless Programming Integration
Compatible with Schneider’s SoMachine (EcoStruxure Machine Expert) environment, offering motion libraries and PLCopen standard motion function blocks for fast development.
Technical FAQs
1. What is the core purpose of this motion controller?
It executes motion-focused logic for coordinated multi-axis systems while handling I/O and communication in one compact unit.
2. How many discrete inputs and outputs are supported?
It features up to 42 discrete I/O points for digital control and feedback.
3. What communication protocols are supported?
The controller supports Ethernet, CANopen Master, CANmotion Master, serial (RS232/RS485), and USB interfaces.
4. Can this controller handle high-speed events?
Yes — it includes 8 high-speed counters capable of 200 kHz operation.
5. What programming environment is used?
Motion and logic programming is supported via Schneider’s SoMachine or EcoStruxure Machine Expert tools.
6. What power supply does it require?
It operates on a 24 V DC supply.
7. Is the unit suitable for harsh industrial environments?
It’s designed to IP20 standards with industrial-level certifications for reliable operation.
8. Does it have built-in status indicators?
Yes — LEDs indicate controller and communication port status for quick visual diagnostics.
9. What are typical mounting options?
DIN-rail mounting makes installation straightforward within standard control cabinets.
10. Is there onboard memory for applications?
Yes — 128 MB Flash and 64 MB RAM provide space for motion logic and machine programs.
