Schneider BMXDRA0805 Discrete Output Module

Brand:Schneider PLC
Item No.:BMXDRA0805
Product Origin:France
Product Dimensions:90 × 22 × 115 mm
Product Weight:0.12kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

BMXDRA0805Schneider BMXDRA0805-3Schneider BMXDRA0805-2Schneider BMXDRA0805-1Schneider BMXDRA0805-4

Introduction

The Schneider BMXDRA0805 Discrete Output Module is a compact, high‑performance digital output unit designed for industrial PLC systems in the Modicon X80 automation platform. This module provides 8 discrete relay outputs, enabling reliable control of external devices such as contactors, solenoids, indicator lamps, and low‑power actuators. Its relay‑based outputs ensure robust electrical isolation between control logic and field devices, making it suitable for applications where galvanic separation and wide load tolerance are important.

Technical Specifications

SpecificationDetails
Model NumberBMXDRA0805
Module TypeDiscrete Output Module (Relay)
PlatformModicon X80 series
Number of Outputs8 relay isolated discrete outputs
Output TypeElectromechanical relay outputs
Contact Rating (per output)Up to 2 A at 30 V DC / 2 A at 250 V AC
Output IsolationGalvanic isolation between outputs and control logic
Status IndicatorsLED per output channel
Switching CapabilityRelay switching for discrete field devices
Operating Temperature0 °C to +60 °C
Storage Temperature‑40 °C to +85 °C
Relative Humidity5–95% non‑condensing
Protection RatingIP20
MountingDIN rail / backplane compatible


Applications

This discrete output module is widely used in industrial and commercial automation where relay‑level switching is needed:

  • Contactor and Motor Starter Control – Switching contactors or providing signals to motor starters

  • Alarm and Indicator Control – Driving indicator lights, buzzers, and signal towers

  • Solenoid and Valve Actuation – Operating solenoid valves in pneumatic/hydraulic systems

  • Machine Interlock Logic – Enforcing safety and sequence logic via discrete outputs

  • Building Automation – Control of lights, relays, and peripheral devices in large systems

Because of its relay outputs, BMXDRA0805 is ideal when output loads vary between DC and AC or require high voltage isolation.


Advantages

  • Galvanic Isolation via Relays – Provides strong electrical separation between control circuits and field loads

  • Flexible Load Compatibility – Relay outputs can switch AC and DC devices with different load characteristics

  • Visual Output Status – Individual LED indicators simplify monitoring and troubleshooting

  • Compact Industrial Design – Designed for efficient integration into X80 backplane or DIN rail applications

  • Wide Environmental Tolerance – Suitable for typical industrial temperature and humidity conditions

  • Reliable Switching Performance – Electromechanical relays ensure dependable operation for discrete loads


Technical FAQs

  1. How many discrete outputs does this module provide?
    It provides 8 relay‑based discrete outputs.

  2. What types of loads can it switch?
    Both AC and DC loads, including lamps, contactors (via intermediate relays), solenoids, and other devices within contact ratings.

  3. What is the maximum current per output?
    Each relay contact typically supports up to 2 A at 30 V DC or 2 A at 250 V AC.

  4. Is the output isolated from the PLC logic?
    Yes, relay contacts provide galvanic isolation between outputs and the control bus.

  5. Does the module offer visual status indicators?
    Yes, individual LED indicators show the real‑time state of each output.

  6. What mounting options are supported?
    Designed for DIN rail mounting and integration into X80 PLC backplane systems.

  7. What is the operating temperature range?
    The module operates reliably from 0 °C to +60 °C.

  8. What protection rating does the module have?
    IP20, suitable for indoor industrial environments.

  9. Is this module suitable for noisy industrial environments?
    Yes, relay outputs with galvanic isolation help maintain signal integrity and reduce interference.

  10. Can it be used with mixed load types?
    Yes, it can switch different AC and DC loads within rated limits, offering flexibility across applications.
