Schneider BMXDDO1612 Discrete Output Module

Brand:Schneider PLC
Item No.:BMXDDO1612
Product Origin:France
Product Dimensions:100 × 22 × 145 mm
Product Weight:0.12kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

BMXDDO1612 (2)BMXDDO1612 (1)BMXDDO1612 (4)BMXDDO1612 (3)

Introduction

The Schneider BMXDDO1612 Discrete Output Module is a rugged industrial I/O component designed for use within the Modicon X80 automation platform. This module provides 16 discrete outputs capable of driving field devices such as solenoids, contactors, indicators, and actuators. With a focus on strong isolation, robust switching performance, and electrical noise immunity, the BMXDDO1612 is ideal for controlling discrete loads in complex automation systems.

Technical Specifications

SpecificationDetails
Model NumberBMXDDO1612
Module TypeDiscrete Output Module
PlatformModicon X80 series
Number of Outputs16 discrete outputs
Output TypeSinking/NPN or Sourcing/PNP (depending on variant)
Output Voltage24 V DC
Maximum Output Current0.5–2 A per channel (application dependent)
Output IsolationOptically isolated outputs for improved noise immunity
Status IndicatorsLEDs for each output channel
Switching CapabilityFast response suitable for industrial automation
Operating Temperature0 °C to +60 °C
Storage Temperature−40 °C to +85 °C
Relative Humidity5–95% (non‑condensing)
Mounting TypeDIN rail compatible / backplane install
Protection RatingIP20


Applications

The BMXDDO1612 module is suited to a wide range of industrial automation tasks requiring reliable discrete switching:

  • Actuator Control – Driving solenoid valves, pneumatic or hydraulic actuators

  • Indicator and Alarm Systems – Switching lamps, buzzers, and signal towers

  • Contactor and Relay Interfaces – Driving contactors through intermediate relays

  • Material Handling Equipment – Controlling conveyors, diverters, gates, and sorters

  • Machine Sequence Logic – Supporting coordinated operations in automated systems

The module’s high output count and robust design make it a versatile choice in factory automation, process control, and commercial building systems.


Advantages

  • High Output Density – Provides 16 independent discrete outputs for wide control coverage.

  • Industrial Isolation – Optically isolated channels improve noise resistance and signal integrity.

  • Flexible Load Driving – Suitable for a variety of field devices depending on output configuration.

  • Visual Status Monitoring – LED indicators make it easy to verify channel status and aid troubleshooting.

  • Compact Modular Design – Efficient footprint with easy DIN rail or backplane installation.

  • Wide Environmental Support – Designed to perform reliably across typical industrial temperature and humidity ranges.


Technical FAQs

  1. How many discrete outputs does this module provide?
    It provides 16 independent discrete outputs.

  2. What voltage level does it operate at?
    Outputs are typically 24 V DC for standard industrial logic and actuator control.

  3. Are the outputs isolated?
    Yes, the outputs are optically isolated to enhance noise immunity and system safety.

  4. What devices can this module drive?
    It can drive solenoids, contactors (via relays), indicator lamps, and other discrete field devices.

  5. Does the module indicate output status?
    Yes, each output has a dedicated LED status indicator.

  6. How is the module mounted?
    It mounts on a DIN rail or integrates into a PLC backplane within a Modicon X80 system.

  7. What is the temperature operating range?
    Designed to operate from 0 °C to +60 °C.

  8. Is the module suitable for electrically noisy environments?
    Yes, optical isolation and robust industrial design help maintain signal integrity.

  9. What protection rating does the module have?
    It carries an IP20 rating appropriate for industrial control cabinets.

  10. Is this module expandable with other I/O modules?
    Yes, it integrates seamlessly with other X80 I/O modules to build larger control systems.
