Overview
The Schneider Electric ATV630C13N4 Variable Speed Drive is a powerful motor control solution from the Altivar Process ATV600 series, designed for industrial process applications that demand reliability, efficiency, and flexibility. This drive is engineered to provide precise speed control for pumps, fans, compressors, and other rotating machinery.
With advanced motor control algorithms and integrated communication capabilities, the ATV630C13N4 helps industrial facilities reduce energy consumption, improve process stability, and extend equipment lifespan. Its rugged design and intelligent monitoring features make it an excellent choice for automation systems in sectors such as water treatment, oil and gas, mining, and manufacturing.
Technical Specifications
| Specification | Details |
|---|
| Model Number | ATV630C13N4 |
| Product Series | Altivar Process ATV600 |
| Device Type | Variable Speed Drive |
| Rated Motor Power | 132 kW (Normal Duty) / 110 kW (Heavy Duty) |
| Maximum Horsepower | 200 HP ND / 150 HP HD |
| Input Voltage | 380–480 V AC |
| Input Phase | 3-Phase |
| Output Frequency | 0.1 – 500 Hz |
| Rated Output Current | Up to 250 A |
| Switching Frequency | 2 – 8 kHz adjustable |
| Communication Interfaces | Ethernet, Modbus TCP, Modbus Serial |
| Digital Inputs | 8 |
| Analog Inputs / Outputs | 3 AI / 2 AO |
| Relay Outputs | 3 |
| Protection Rating | IP00 (IP21 optional with enclosure kit) |
| Safety Function | STO (Safe Torque Off) SIL3 |
| Cooling Method | Forced convection |
| Operating Temperature | −15 °C to +50 °C (up to 60 °C with derating) |
Applications
The ATV630C13N4 variable speed drive is optimized for demanding industrial environments where efficient motor control and reliable operation are essential.
-
Water and Wastewater Treatment Systems – Pump and blower speed regulation
-
Oil and Gas Processing – Compressor and pump control
-
Mining and Mineral Processing – Heavy-duty motor applications
-
Food and Beverage Manufacturing – Conveyor and mixer speed control
-
Industrial HVAC Systems – Energy-efficient fan and pump operation
Technical FAQs
1. What motor power rating does the ATV630C13N4 support?
It supports motors up to 132 kW in normal duty applications.
2. What voltage supply is required for this drive?
The drive operates with a three-phase 380–480 V AC power supply.
3. What is the maximum output frequency?
The maximum adjustable output frequency is 500 Hz.
4. Does the drive support multiple motor types?
Yes, it supports both asynchronous and permanent magnet synchronous motors.
5. What communication protocols are integrated?
The drive includes Ethernet, Modbus TCP, and Modbus Serial communication.
6. Does the ATV630C13N4 include built-in safety functions?
Yes, it features Safe Torque Off (STO) with SIL3 certification.
7. How is the drive cooled?
The device uses forced convection cooling for effective thermal management.
8. What is the recommended installation method?
It is designed for vertical wall mounting inside control cabinets or panels.
9. What temperature range can the drive operate in?
It operates from −15 °C to +50 °C without derating.
10. What industries commonly use this drive?
Water treatment, mining, oil and gas, HVAC, and manufacturing industries widely use the ATV630 series.
