Technical FAQs

1. What measurement range does this probe support?
   Typically operates over a 2 mm (80 mils) linear range as part of the 3300 XL system.

2. Can this probe operate in high-temperature environments?
   Yes; standard probes function reliably up to +177 °C (+351 °F).

3. Is calibration required after replacement?
   No; 3300 XL probes and cables are interchangeable without recalibration in supported systems.

4. What type of connector is used?
   Miniature coaxial ClickLoc™ connectors ensure secure, tool-free connections.

5. Does it support API‑670 systems?
   Yes; when integrated with compliant Proximitor sensors and monitors, it meets API‑670 mechanical configuration requirements.

6. Is armor available for the cable?
   Armor options are available in other part configurations but not in this specific variant.

7. What materials are used for the probe tip?
   The probe utilizes polyphenylene sulfide (PPS) for tip resilience.

8. Is backward compatibility supported?
   Yes; this 8 mm probe works with previous 3300 series components.

9. How does it handle humidity?
   Design maintains accuracy with minimal change even at high humidity levels.

10. What is the minimum bend radius for extension cables?
    Typical cable designs specify a minimum bend radius of about 25 mm to maintain performance.
