Product Introduction
The GE IC695ETM001 is a dedicated Ethernet Interface Module developed for the PACSystems RX3i automation platform. This module delivers reliable, high‑speed Ethernet connectivity between the RX3i controller and networked devices, enabling seamless data exchange for monitoring, control, and engineering interfaces.
Designed for industrial environments, the IC695ETM001 supports standard Ethernet communication speeds and integrates directly with the RX3i backplane. It is a key component for applications where networked communications, remote access, and data exchange with supervisory systems are required.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC695ETM001 |
| Product Type | Ethernet Interface Module |
| Platform Compatibility | PACSystems RX3i Controllers |
| Network Ports | Dual RJ45 10/100Base‑T |
| Communication Speed | 10/100 Mbps |
| Protocol Support | TCP/IP, UDP, Modbus TCP, industrial Ethernet standards |
| Interface Type | Backplane integrated Ethernet |
| Indicators | Link, activity, status LEDs |
| Mounting | RX3i backplane I/O slot |
| Operating Voltage | +5 V DC (backplane powered) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –20 °C to +70 °C |
| Application | Industrial Ethernet communication, network connectivity |
Industrial Applications
The IC695ETM001 is suitable for a wide range of industrial automation environments that require Ethernet networking:
-
PLC connectivity to HMIs and SCADA systems
-
Remote monitoring and diagnostics
-
Communication with industrial PCs and MES/ERP systems
-
Integration with OPC servers and data historians
-
Real‑time distribution of control and status data
-
Ethernet‑based device communication in distributed systems
Its support for standard Ethernet protocols makes it a versatile choice for connected automation architectures.
Advantages
Flexible Network Connectivity
Enables Ethernet networking for PACSystems RX3i controllers, allowing integration with HMIs, SCADA, and enterprise systems.
Dual Ethernet Ports
Two RJ45 ports provide network flexibility, including daisy‑chain and star topology support.
Standard Protocol Support
Supports TCP/IP, UDP, Modbus TCP, and other common industrial Ethernet protocols.
Easy Backplane Integration
Mounts directly to the RX3i backplane, eliminating the need for external interface hardware.
Diagnostic Indicators
Link, activity, and status LEDs provide real‑time visibility into network operation and troubleshooting.
Industrial‑Grade Reliability
Designed for continuous operation in industrial environments with temperature tolerance and vibration resistance.
Technical FAQs
1. What is the primary function of the IC695ETM001?
It provides Ethernet connectivity for PACSystems RX3i controllers, enabling network communication.
2. How many Ethernet ports does it have?
Two RJ45 10/100Base‑T network ports.
3. What communication speeds are supported?
10 Mbps and 100 Mbps Ethernet.
4. Does it support common industrial protocols?
Yes — it supports standard Ethernet protocols such as TCP/IP, UDP, and Modbus TCP.
5. How is the module powered?
Powered by the RX3i backplane’s +5 V DC supply.
6. What temperature range does it operate in?
0 °C to +60 °C.
7. Is diagnostic feedback available?
Yes — link, activity, and status indicator LEDs are provided.
8. Where is this module installed?
In an RX3i backplane I/O slot.
9. Can it be used for remote diagnostics?
Yes — Ethernet connectivity enables remote access and monitoring.
10. Which industries commonly use this module?
Manufacturing, energy, process control, water & wastewater treatment, and distributed automation systems.
