Product Introduction
The GE IC695NIU001 is an industrial‑grade Ethernet Interface Unit built for the PACSystems RX3i automation platform. This module provides native Ethernet connectivity to the RX3i system, enabling high‑speed data exchange, remote access, and integration with modern networked control environments. Designed for demanding applications, the NIU enhances communication between the PACSystems controller and supervisory systems, HMIs, SCADA, MES, and other Ethernet‑compatible devices.
With support for standard industrial Ethernet protocols and reliable backplane integration, the IC695NIU001 plays a critical role in distributed systems where fast, secure, and scalable communication is essential. Its robust design ensures consistent performance in industrial settings where uptime and data integrity are priorities.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC695NIU001 |
| Product Type | Ethernet Interface Unit |
| Platform Compatibility | PACSystems RX3i Controllers |
| Network Ports | Dual RJ45 10/100 Mbps |
| Protocol Support | TCP/IP, Modbus TCP, Ethernet communications |
| Mounting | RX3i backplane I/O slot |
| Operating Voltage | Backplane +5 V DC |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –20 °C to +70 °C |
| Indicators | Link/Activity LEDs |
| Application | Industrial Ethernet communication |
Industrial Applications
The IC695NIU001 Ethernet Interface Unit is used in applications where networked communication is required:
-
Remote connectivity between PLC systems and HMI/SCADA
-
Ethernet‑based data acquisition and monitoring
-
Distributed automation and control systems
-
Interfacing with enterprise systems and OPC servers
-
Integration with Industrial IoT (IIoT) platforms
-
Real‑time Ethernet machine control
By providing native Ethernet connectivity, the NIU simplifies network architecture and supports faster diagnostics, programming, and real‑time communication.
Advantages
High‑Speed Ethernet Communication
Supports 10/100 Mbps Ethernet for rapid data transfer and responsive control system interactions.
Standard Protocol Support
Compatible with widespread industrial communication protocols such as TCP/IP and Modbus TCP.
Seamless Backplane Integration
Connects directly to the RX3i backplane, maintaining system integrity and reducing hardware complexity.
Diagnostic LEDs
Provides intuitive visual feedback for link status and network activity, simplifying troubleshooting.
Industrial‑Rated Performance
Designed for continuous operation in industrial environments, with temperature tolerance and vibration resistance.
Technical FAQs
-
What is the primary function of the IC695NIU001?
It provides Ethernet connectivity for PACSystems RX3i controllers.
-
How many Ethernet ports are available?
Two RJ45 ports supporting 10/100 Mbps.
-
Which protocols does it support?
Standard Ethernet protocols, including TCP/IP and Modbus TCP.
-
Where is it installed?
In an RX3i backplane I/O slot.
-
Does it require external power?
No — it is powered by the backplane’s +5 V supply.
-
What temperature range does it support?
0 °C to +60 °C.
-
Does it support remote monitoring?
Yes, through Ethernet‑based communication.
-
Can it be used in distributed control systems?
Yes, when network architecture supports Ethernet communications.
-
Does it provide diagnostic indicators?
Yes — link and activity LEDs are included.
-
Which industries commonly use this module?
Manufacturing, energy, process control, water treatment, and any Ethernet‑based automation systems.
