Product Introduction
The GE IC695NIU001 is a dedicated Ethernet Interface Unit engineered for the PACSystems RX3i automation platform. This communication module provides robust Ethernet connectivity between RX3i controllers and industrial Ethernet networks, enabling high‑speed data exchange, remote monitoring, and integration with supervisory systems. Designed for demanding industrial environments, the IC695NIU001 supports reliable real‑time communication and seamless integration with Ethernet‑based devices such as HMIs, SCADA systems, and distributed controllers.
Whether deployed in manufacturing automation, process control, or infrastructure systems, this interface unit enhances overall system performance by extending network reach and enabling efficient machine‑to‑machine communication. Its compact design and industrial reliability make it an essential component for modern RX3i network architectures.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC695NIU001 |
| Product Type | Ethernet Interface Unit |
| Platform Compatibility | PACSystems RX3i Controllers |
| Network Protocols | TCP/IP, UDP, Modbus TCP, SRTP, HTTP, FTP |
| Ports | Dual RJ45 10/100Base‑T Ethernet |
| Communication Speed | 10/100 Mbps |
| Mounting | RX3i backplane I/O slot |
| Operating Voltage | +5 V DC (backplane powered) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –20 °C to +70 °C |
| Indicators | Status LEDs for Link, Activity, Error |
| Application | Industrial Ethernet communication and remote access |
Industrial Applications
The IC695NIU001 Ethernet Interface Unit is widely used in automation systems that require robust Ethernet connectivity:
-
Integrating PACSystems RX3i controllers with HMIs and SCADA
-
Remote access for monitoring and diagnostics
-
Data exchange with MES and enterprise systems
-
Distributed Ethernet‑based I/O and control networks
-
Ethernet connectivity for industrial PCs and storage systems
-
Machine‑to‑machine communications in automated factories
Its support for standard Ethernet protocols makes it suitable for modern industrial network architectures.
Advantages
High‑Speed Ethernet Connectivity
Supports dual 10/100 Mbps Ethernet ports for reliable, high‑speed network communication.
Broad Protocol Support
Compatible with TCP/IP, UDP, Modbus TCP, SRTP, HTTP, and FTP, enabling diverse communication scenarios.
Status and Diagnostic Feedback
Integrated LEDs provide real‑time visibility into link status, traffic activity, and error conditions.
Seamless RX3i Integration
Designed specifically for PACSystems RX3i backplane interfaces, ensuring stable and efficient communication.
Industrial‑Grade Reliability
Constructed for continuous operation in harsh environments, including vibration and temperature variations.
Technical FAQs
1. What is the primary function of the IC695NIU001?
It provides Ethernet connectivity for PACSystems RX3i controllers to communicate with external networks and devices.
2. Which network protocols does it support?
It supports TCP/IP, UDP, Modbus TCP, SRTP, HTTP, and FTP.
3. How many Ethernet ports does this module have?
It has two RJ45 10/100 Mbps Ethernet ports.
4. Can it be used for remote system access?
Yes, it supports remote monitoring and diagnostics via standard Ethernet protocols.
5. Does it support connection to SCADA systems?
Yes, it integrates with SCADA, HMI, and MES systems over Ethernet.
6. What is the operating temperature range?
0 °C to +60 °C.
7. How is this module powered?
It is powered by the RX3i backplane’s +5 V DC supply.
8. Is it compatible with distributed Ethernet systems?
Yes, it is designed for Ethernet‑based distributed control networks.
9. Does it include diagnostic indicators?
Yes, LEDs display link, activity, and error status.
10. Which industries commonly use this interface unit?
Manufacturing, process control, energy, and infrastructure automation systems.
