Product Introduction
The GE IC695PNC001 is a high‑performance PROFINET Controller Module developed for the PACSystems RX3i automation platform. This module enables RX3i systems to act as a PROFINET controller, managing and coordinating communication with PROFINET IO devices such as remote I/O, drives, HMIs, and smart sensors. PROFINET is an industry‑standard Ethernet real‑time protocol widely used in modern automation systems for deterministic data exchange and seamless integration.
By incorporating the IC695PNC001, PACSystems RX3i controllers can participate in advanced industrial networks, supporting flexible topologies and high‑speed communication. The module enhances the RX3i architecture with scalable networking, device diagnostics, and efficient data management, helping engineers build connected, future‑ready automated systems.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC695PNC001 |
| Product Type | PROFINET Controller Module |
| Platform Compatibility | PACSystems RX3i Controllers |
| PROFINET Support | PROFINET IO Controller (Class A/B) |
| Network Ports | Dual RJ45 10/100Base‑T |
| Communication Speed | 10/100 Mbps |
| Supported Devices | PROFINET IO Devices (remote I/O, drives, etc.) |
| Mounting | RX3i backplane I/O slot |
| Operating Voltage | +5 V DC (backplane powered) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –20 °C to +70 °C |
| Status Indicators | LEDs for Link, Activity, Status, Error |
| Application | Industrial Ethernet communication and PROFINET network control |
Industrial Applications
The IC695PNC001 module enables advanced networking capabilities for a wide range of control systems:
-
Factory automation systems with distributed PROFINET I/O
-
Coordinating PROFINET remote devices in process control
-
Machine and motion control integrating EtherNet‑based devices
-
Integration with SCADA, MES, and enterprise networking layers
-
Drive and motor control networks with real‑time requirements
-
Industrial installations requiring robust, deterministic Ethernet communication
This controller module helps bridge traditional PLC architectures with modern Ethernet‑centric ecosystems.
Advantages
Native PROFINET Controller Integration
Transforms PACSystems RX3i into a fully capable PROFINET IO controller, enabling centralized management of networked devices.
Dual Ethernet Ports
Two RJ45 ports support flexible network topology designs (linear, ring, star) and redundancy where required.
Real‑Time Communication
Supports 10/100 Mbps industrial Ethernet speeds and deterministic data exchange for high‑performance automation.
Comprehensive Diagnostics
Status LED indicators provide real‑time visibility into link, communication activity, and errors, simplifying maintenance and fault finding.
Seamless System Compatibility
Designed to integrate smoothly with PACSystems RX3i backplane and control architecture, preserving system performance and reliability.
Technical FAQs
1. What is the main purpose of the IC695PNC001?
It operates as a PROFINET IO controller, managing communication with PROFINET devices.
2. Which platform is it compatible with?
PACSystems RX3i control systems.
3. How many Ethernet ports does it have?
Two RJ45 10/100 Mbps Ethernet ports.
4. What PROFINET class does it support?
It supports PROFINET IO Controller functionality (Class A/B as per application requirements).
5. What communication speeds are supported?
10/100 Mbps industrial Ethernet.
6. Can it manage multiple PROFINET devices?
Yes, within the limits of network design and module firmware capabilities.
7. What diagnostic feedback is available?
LED indicators for link status, activity, status, and communication errors.
8. What temperature range is supported?
0 °C to +60 °C operating temperature.
9. Does it support integration with SCADA systems?
Yes — PROFINET networking allows communication with SCADA and higher‑level systems.
10. Is this module suitable for real‑time control networks?
Yes, it is engineered for deterministic data exchange in industrial automation.
