Product Introduction
The GE IC695PNS001 is a dedicated PROFINET Scanner Module designed for the PACSystems RX3i automation platform. This communication module enables seamless integration of RX3i controllers with PROFINET‑based industrial networks, allowing PLCs to exchange data with PROFINET devices such as I/O stations, drives, HMIs, and field instruments.
Engineered for high‑speed and deterministic industrial communication, the IC695PNS001 supports real‑time data exchange in production and process automation. It adheres to PROFINET protocol standards, enabling flexible network topologies, device diagnostics, and efficient engineering workflows. This module is ideal for modern automated systems where Ethernet‑based connectivity and interoperability are required to meet demanding control and monitoring needs.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC695PNS001 |
| Product Type | PROFINET Scanner Module |
| Platform Compatibility | PACSystems RX3i Controllers |
| Protocol Support | PROFINET RT (Real Time) |
| Network Ports | Dual RJ45 10/100Base‑T ports |
| Maximum Devices Supported | Depend on network design and module firmware |
| Communication Speed | 10/100 Mbps |
| Mounting | RX3i backplane slot |
| Operating Voltage | +5 V DC (backplane powered) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | −20 °C to +70 °C |
| Indicators | Status LEDs for link, activity, and errors |
| Application | Industrial Ethernet communications and PROFINET networking |
Industrial Applications
The IC695PNS001 PROFINET Scanner Module supports industrial automation systems that rely on Ethernet‑based communication protocols:
-
Factory automation requiring real‑time device communication
-
Integration with PROFINET‑based I/O stations and smart sensors
-
Drive and motion control networking
-
Process control systems with distributed Ethernet I/O
-
SCADA and MES connectivity over industrial Ethernet
-
System architecture requiring deterministic, high‑speed communication
By enabling PROFINET connectivity, this module allows PACSystems RX3i controllers to participate in modern, Ethernet‑based automation networks.
Advantages
Native PROFINET Support
Provides full PROFINET RT scanning capabilities, enabling RX3i systems to communicate with PROFINET devices in real time.
Dual Ethernet Ports
Two RJ45 ports support flexible network topology designs such as linear, star, or ring architectures.
High‑Speed Communications
Supports 10/100 Mbps industrial Ethernet speeds for efficient data exchange and reduced latency.
Status and Diagnostic Indicators
Integrated LEDs provide real‑time feedback on link status, activity, and error conditions, simplifying troubleshooting.
Seamless Integration with RX3i
Designed to work natively with PACSystems RX3i backplane and firmware, ensuring stable and efficient operation.
Technical FAQs
1. What communication protocol does the IC695PNS001 support?
It supports PROFINET RT (Real Time) communications.
2. How many Ethernet ports are available on the module?
It has two RJ45 10/100Base‑T Ethernet ports.
3. Can this module connect to multiple PROFINET devices?
Yes, the number of supported devices depends on network design and configuration.
4. What controller platform is it compatible with?
It is compatible with PACSystems RX3i controllers.
5. What is the operating temperature range?
It operates between 0 °C and +60 °C.
6. How is this module mounted?
It installs into an RX3i backplane I/O slot.
7. What speeds does it support?
It supports 10/100 Mbps industrial Ethernet speeds.
8. Does it include diagnostic indicators?
Yes, it includes LEDs for link, activity, and error status.
9. Is it suitable for real‑time control networks?
Yes, PROFINET RT support enables real‑time industrial communication.
10. Which industries commonly use this scanner module?
Factory automation, process control, motion control, and systems requiring Ethernet networking.
