System Overview
The GE IC698CPE020 is a powerful CPU Module developed for the PACSystems RX7i programmable automation controller platform. Acting as the central processing unit of the system, it is responsible for executing user programs, managing communication tasks, and coordinating all connected I/O modules.
Built for demanding industrial environments, this CPU module delivers high-speed processing performance and dependable real-time control. It integrates easily into large-scale automation architectures and supports advanced networking, making it an ideal choice for complex industrial systems that require precision, scalability, and continuous operation.
With its robust design and flexible communication capabilities, the IC698CPE020 provides a reliable foundation for mission-critical automation applications across multiple industries.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC698CPE020 |
| Product Type | CPU Module |
| Platform | PACSystems RX7i |
| Processor | 700 MHz Pentium III |
| User Memory | 10 MB battery-backed RAM |
| Flash Memory | 10 MB non-volatile memory |
| Programming Languages | Ladder Diagram, Structured Text, Function Block Diagram, C |
| Ethernet Ports | 2 × RJ45 10/100 Mbps |
| Serial Ports | 2 × RS-232 / RS-485 + 1 Station Manager RS-232 |
| Supported Protocols | SRTP, Modbus TCP, Ethernet Global Data (EGD), Modbus RTU, SNP |
| Maximum Program Blocks | 512 |
| Maximum Program Block Size | 128 KB |
| I/O Memory | 32 Kbits Discrete, 32 Kwords Analog |
| Operating Voltage | 5–12 V DC |
| Backplane Current | Approx. 4.5 A @ 5 V DC |
Industrial Applications
The IC698CPE020 CPU is widely deployed in automation environments requiring high processing power and reliable communication infrastructure.
Typical applications include:
-
Large-scale industrial automation systems
-
Distributed control systems (DCS)
-
Manufacturing and assembly line automation
-
Power generation and energy management
-
Oil & gas process control
-
SCADA-integrated monitoring and control platforms
Its capability to manage extensive I/O networks and complex control algorithms makes it well suited for mission-critical industrial operations.
Key Advantages
High-Speed Processing Power
Equipped with a 700 MHz processor, the module delivers fast execution of control logic and floating-point calculations for demanding automation tasks.
Large Program and Data Capacity
The 10 MB battery-backed memory and 10 MB flash storage support large automation programs and data logging requirements.
Flexible Communication Architecture
Dual Ethernet ports and multiple serial interfaces enable seamless communication with HMIs, SCADA systems, and remote I/O devices.
Advanced Industrial Networking
Supports widely used industrial protocols such as Modbus TCP, SRTP, and Ethernet Global Data for efficient data exchange.
Reliable Continuous Operation
Designed for 24/7 industrial environments, ensuring dependable performance in high-availability control systems.
Technical FAQs
1. What is the primary function of the IC698CPE020 CPU module?
It executes automation programs and manages communication between I/O modules and industrial networks.
2. What processor does the module use?
The module is equipped with a 700 MHz Pentium III processor.
3. How much memory does the CPU provide?
It includes 10 MB of battery-backed RAM and 10 MB of flash memory.
4. How many Ethernet ports are available?
The module includes two built-in Ethernet ports for industrial network communication.
5. What programming languages are supported?
It supports Ladder Diagram, Structured Text, Function Block Diagram, and C programming.
6. Can the CPU communicate with SCADA systems?
Yes, it supports communication protocols that allow integration with SCADA platforms.
7. What serial communication options are included?
The module offers RS-232 and RS-485 serial ports for additional device connectivity.
8. What is the maximum number of program blocks supported?
Up to 512 program blocks can be stored within the CPU.
9. Is the module suitable for high-availability systems?
Yes, it can be used in redundant architectures designed for high system reliability.
10. Which configuration software is typically used with this module?
It is commonly configured using industrial PLC programming software designed for PACSystems platforms.
