Product Overview
The GE IC698CPE030 is a high-performance CPU Module designed for the PACSystems RX3i platform. It acts as the central processing hub, executing control logic, managing I/O operations, and coordinating communication across the system. Built for demanding industrial applications, this CPU module delivers reliable real-time performance for manufacturing, process control, and power generation environments.
Featuring advanced processing capabilities and robust construction, the IC698CPE030 ensures continuous operation under vibration, temperature changes, and industrial electrical noise. It supports deterministic control, multi-task processing, and seamless integration with Ethernet, power, and I/O modules, making it a versatile solution for modern automation systems.
This CPU module is ideal for operators who require high-speed control, large memory capacity, and fault-tolerant system operation.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE (General Electric) |
| Model Number | IC698CPE030 |
| Product Type | CPU Module |
| Platform Compatibility | PACSystems RX3i Controllers |
| Processor | High-speed embedded CPU |
| User Memory | 2 MB |
| Communication Interfaces | Ethernet, Serial, I/O Bus |
| Operating Voltage | 5 V DC |
| Mounting | DIN rail / Panel mount |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Dimensions | 150 × 100 × 50 mm |
| Weight | Approx. 0.78 kg |
| Application | Real-time process control, industrial automation, high-speed PLC operations |
Applications
The IC698CPE030 CPU Module is widely used in industrial automation systems where reliable, high-speed control is essential:
-
Distributed and centralized process control systems
-
Manufacturing and assembly automation
-
Power generation control applications
-
Integration with RX3i Ethernet and I/O modules
-
Real-time monitoring and control through SCADA/HMI systems
-
High-speed data acquisition in industrial automation
Its large memory and fast processing capabilities allow complex control programs and multi-task operations to run efficiently.
Advantages
High-Speed Control
Executes complex control algorithms with minimal latency, ensuring real-time system performance.
Extended Memory
2 MB user memory supports larger applications and extensive data logging.
Flexible Communication
Supports Ethernet, serial, and I/O bus connections for distributed automation.
Industrial-Grade Reliability
Designed for continuous operation in harsh industrial conditions, including vibration and temperature variations.
Simplified Maintenance
Plug-and-play design allows for quick installation and replacement with minimal downtime.
Technical FAQs
1. What is the primary function of the IC698CPE030?
It serves as the main CPU, executing control logic and coordinating I/O operations.
2. How much memory does it have?
2 MB of user memory.
3. What communication interfaces are supported?
Ethernet, serial, and PACSystems RX3i I/O bus.
4. What is the operating temperature range?
0°C to +60°C.
5. Can it be mounted in standard control cabinets?
Yes, it supports DIN rail and panel mounting.
6. Is it suitable for distributed control systems?
Yes, fully compatible with distributed RX3i architectures.
7. Can it operate continuously 24/7?
Yes, it is designed for continuous industrial operation.
8. Which industries typically use this module?
Manufacturing, process automation, power generation, and chemical processing.
9. Is it optimized for real-time, high-speed control?
Yes, it provides deterministic, low-latency control.
10. Is maintenance and replacement straightforward?
Yes, plug-and-play design ensures minimal downtime.
