Product Introduction
The GE IC694ACC300 Input Simulator Module is a specialized industrial simulation board designed for GE Fanuc / GE Series 90‑70 and Series 90‑30 PLC systems. This module provides controlled, accurate simulated input signals to the PLC for testing, diagnostics, calibration, and system verification without the need for physical field sensors.
Engineered for high reliability and ease of use, the IC694ACC300 helps engineers and technicians validate control logic, troubleshoot system responses, and perform maintenance activities in complex automation environments. Its capability to simulate discrete and analog inputs makes it a valuable tool in manufacturing, process control, power generation, and machinery testing applications.
With robust construction and straightforward module integration, this simulator supports repeatable, consistent testing procedures that help reduce downtime and improve commissioning accuracy.
Technical Specifications
| Specification | Detail |
|---|
| Brand | GE (General Electric) |
| Model | IC694ACC300 |
| Module Type | Input Simulator Module |
| Series | Series 90‑30 / Series 90‑70 PLC Platforms |
| Function | I/O Signal Simulation and Testing |
| Simulated Inputs | Discrete and Analog (application dependent) |
| System Interface | PLC Backplane / Rack Connector |
| Mounting | PLC Rack / Control Cabinet |
| Operating Temperature | 0°C – 55°C |
| Storage Temperature | –40°C – 85°C |
| Relative Humidity | 5% – 95% Non‑condensing |
| Protective Design | Rugged Industrial Build |
| Cooling | Passive Airflow |
| Dimensions | Standard Series PLC Module Size |
| Weight | Approx. 0.45 kg |
Applications
The IC694ACC300 Input Simulator Module is designed for testing and diagnostic applications where simulated electrical inputs are required.
Typical use cases include:
-
Commissioning PLC systems during installation
-
Testing control logic without field sensor activation
-
Verifying sensor fault handling and alarm conditions
-
System troubleshooting and maintenance diagnostics
-
Calibration of input signal processing algorithms
-
Hardware‑in‑the‑loop (HIL) and test bench simulations
This module enables system engineers to simulate input conditions with precision, improving confidence in control logic and reducing field downtime.
Core Advantages
Accurate Input Simulation
Provides reliable, repeatable simulation of discrete and analog signals for testing and validation.
Versatile Diagnostics Tool
Supports multiple input types and scenarios, enhancing system troubleshooting effectiveness.
Reduces Downtime
Enables testing without field device involvement, minimizing interruption to live systems.
Industrial‑Grade Reliability
Built with rugged components to maintain performance in demanding environments.
Seamless PLC Integration
Designed to plug directly into Series 90‑30 and Series 90‑70 PLC racks, simplifying setup.
Technical FAQs
1. What is the main purpose of the IC694ACC300?
It simulates PLC input signals for testing, diagnostics, and calibration.
2. Which PLC platforms support this module?
It is compatible with GE Series 90‑30 and Series 90‑70 PLC systems.
3. What types of inputs can it simulate?
It can simulate discrete and analog input signals depending on configuration.
4. Where is it installed?
It installs directly into the PLC rack alongside other I/O and controller modules.
5. Can this module be used for field testing?
Yes, it is specifically designed for controlled field testing and diagnostics.
6. Does it affect live signals?
No, it provides separate simulated inputs without interfering with live field devices.
7. What temperature range can it handle?
It operates reliably between 0°C and 55°C.
8. Is external hardware needed to use it?
No external hardware is required; it interfaces directly with the PLC backplane.
9. Can it be used during commissioning?
Yes, it is ideal for pre‑startup commissioning and function verification.
10. Why is this module valuable in automation systems?
It helps verify control logic and troubleshoot systems without disturbing field instrumentation.
