Introduction
The Woodward 8200-1311 I/O Module is part of the Woodward 8200-series control system, designed to interface field devices with the central control logic. This module provides reliable signal acquisition and distribution for analog and discrete signals, enabling precise monitoring and control of industrial processes. Built for rugged industrial environments, the 8200-1311 module ensures signal integrity, electrical isolation, and seamless integration with Woodward PLCs and controllers.
Technical Specifications
(Dimensions and weight are estimated based on standard 8200-series I/O modules.)
| Parameter | Specification / Estimate |
|---|---|
| Module Type | I/O Module |
| Model Number | 8200-1311 |
| Manufacturer | Woodward |
| Primary Function | Field signal acquisition and distribution for analog and discrete I/O |
| Supported Signals | Digital inputs, digital outputs, analog inputs, analog outputs (depending on installed configuration) |
| Isolation | Channel-to-channel and channel-to-bus electrical isolation |
| Diagnostics | Channel status, fault detection, communication monitoring |
| Mounting | Rack or panel mount in 8200-series control system enclosure |
| Dimensions (H × W × D) | 210 × 135 × 40 mm |
| Weight | ≈ 0.9 kg |
| Construction | Multi-layer PCB with rugged connectors, terminal blocks, and industrial-grade housing |
| Communication Interface | Standard Woodward 8200-series backplane bus |
