Product Introduction
The IMASI02S functions as a critical interface between field instrumentation and the distributed control system. By converting analog field signals into accurate digital data, it enables real-time monitoring and closed-loop process control.
Designed for industrial reliability, the module is well-suited for retrofit projects and system expansions within established Bailey automation platforms. Its robust signal handling and stable performance contribute to long-term operational continuity in demanding environments.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB Bailey |
| Model | IMASI02S |
| Module Type | Analog Input Module |
| Input Type | Analog (current/voltage depending on configuration) |
| Mounting | DCS Rack Installation |
| Application | Process signal acquisition |
| Operating Environment | Industrial control cabinets |
| Dimensions (H × W × D) | 200 × 150 × 40 mm |
| Weight | 0.5 kg (≈ 1.10 lb) |
Engineered for Process Signal Acquisition
The ABB Bailey IMASI02S Analog Input Module is designed for precise acquisition of analog process signals in distributed control environments. Commonly deployed within legacy and extended Bailey INFI 90 systems, this module converts field analog signals into digital values for real-time control, monitoring, and data logging.
Typical applications include:
-
Power generation plants
-
Oil & gas processing units
-
Petrochemical facilities
-
Water and wastewater treatment systems
-
Continuous manufacturing industries
Its architecture supports stable measurement performance in electrically noisy industrial environments.
Performance Advantages in Control Systems
High-Accuracy Signal Conversion
Ensures reliable analog-to-digital conversion for critical process variables such as temperature, pressure, flow, and level.
Multi-Channel Capability
Supports multiple field inputs within a single module, optimizing cabinet space and system scalability.
Noise Immunity
Designed to operate reliably in high-EMI environments typical of heavy industrial installations.
Seamless DCS Integration
Fully compatible with Bailey distributed control system backplanes and control architectures.
Industrial-Grade Reliability
Built for continuous 24/7 operation in mission-critical control rooms.
Technical FAQs
1. What types of input signals does the IMASI02S support?
It supports standard industrial analog signals such as 4–20 mA and voltage inputs, depending on configuration.
2. Is the module isolated?
Yes, channel isolation is provided to protect control electronics from field-side disturbances.
3. How is configuration performed?
Configuration is handled through the host control system engineering tools.
4. What process variables are typically connected to this module?
Common signals include transmitters for pressure, temperature, flow, and level.
5. Can it be used in redundant control systems?
Yes, it can be integrated into redundant system architectures depending on system design.
6. What affects measurement accuracy?
Calibration, wiring quality, grounding, and environmental conditions.
7. Does it support hot swapping?
Hot swap capability depends on the system rack and installation design.
8. How is signal scaling handled?
Scaling is performed within the control system configuration software.
9. What diagnostic features are available?
The system can detect signal out-of-range conditions and communication faults.
10. Is it suitable for hazardous area installations?
It may be used with appropriate barriers or intrinsic safety interfaces as required by the application.
