Module Overview
The IC200MDL742H functions as a discrete actuation interface within the VersaMax I/O ecosystem. It converts controller logic signals into physical switching actions at the field level, enabling coordinated control of machinery and process equipment.
Designed for OEM builders and system integrators, the module balances mechanical compactness with electrical robustness. Its lightweight construction and efficient power usage support installation in distributed control panels where space optimization and reliability are equally important.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE Fanuc |
| Series | VersaMax |
| Model | IC200MDL742H |
| Module Type | Discrete Output Module |
| Output Type | Digital (Discrete) |
| Mounting | VersaMax I/O Carrier (DIN Rail) |
| Protection | Short-circuit and overload protection |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (H × W × D) | 110 × 66.8 × 50 mm |
| Weight | 0.15 kg (≈ 0.33 lb) |
Real-World Application Environment
The GE Fanuc IC200MDL742H VersaMax Discrete Output Module is engineered for distributed industrial automation systems requiring dependable digital switching performance. As part of the VersaMax modular I/O family, it provides reliable field-level control while maintaining a compact DIN-rail footprint.
It is frequently implemented in:
-
OEM packaging and labeling machinery
-
Conveyor and intralogistics systems
-
Automotive assembly cells
-
Water and wastewater skid systems
-
Distributed manufacturing workstations
Its modular architecture supports scalable I/O expansion close to field devices, reducing wiring complexity and improving response times.
Performance Characteristics and Design Strengths
Consistent Digital Output Control
Delivers stable ON/OFF switching suitable for industrial relays, solenoids, and contactors.
Compact Modular Construction
Optimized for high-density installations in space-constrained control cabinets.
Integrated Channel Status LEDs
Provides immediate visual indication of output state for faster diagnostics.
Backplane-Powered Simplicity
Receives operating power through the VersaMax carrier, minimizing external wiring.
Industrial Protection Features
Designed with built-in overload and short-circuit protection to enhance system reliability.
Technical FAQs
1. What output type does the IC200MDL742H provide?
It provides discrete digital outputs for industrial load control applications.
2. What types of devices can it control?
Common loads include relays, solenoids, indicator lamps, and motor starters within rated limits.
3. Is the module electrically isolated?
Yes, isolation protects the control circuitry from field-side electrical disturbances.
4. How is the module installed?
It mounts onto a VersaMax I/O carrier attached to a DIN rail.
5. Does it support distributed I/O configurations?
Yes, it integrates seamlessly into distributed VersaMax systems.
6. What determines output switching speed?
Switching timing aligns with the PLC scan cycle and module design specifications.
7. Are outputs grouped by common reference?
Channel grouping depends on wiring configuration and module design.
8. Is hot swapping supported?
Hot insertion capability depends on the overall system architecture and installation guidelines.
9. How are faults indicated?
LED indicators provide channel-level status feedback and help identify output issues.
10. How is configuration performed?
Configuration is handled within the GE Fanuc programming software used for VersaMax systems.
