Module Overview
The IC200MDL730 serves as a digital actuation interface within the VersaMax modular I/O family. It converts controller logic commands into physical switching actions at the field level.
Designed for OEMs and integrators, the module balances compact mechanical design with dependable electrical performance. Its snap-in mounting and backplane connectivity simplify installation, while integrated diagnostics reduce maintenance time.
In distributed automation architectures, this module provides reliable discrete output control close to the point of operation.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE Fanuc |
| Series | VersaMax |
| Model | IC200MDL730 |
| Module Type | Discrete Output Module |
| Output Type | Digital (Discrete) |
| Backplane Interface | VersaMax I/O Carrier |
| Protection Features | Short-circuit and overload protection |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (H × W × D) | 110 × 66.8 × 50 mm |
Application Footprint in Modular Control Systems
The GE Fanuc IC200MDL730 VersaMax Discrete Output Module is designed for compact, distributed I/O architectures where reliable digital actuation is essential. As part of the VersaMax platform, it provides field-level output control for motors, solenoids, relays, and indicator devices within space-constrained panels.
It is commonly deployed in:
-
OEM machinery and packaging equipment
-
Conveyor and material handling systems
-
Automotive assembly fixtures
-
Water treatment skid systems
-
Distributed control nodes in manufacturing cells
Its compact footprint and modular snap-in design make it particularly suitable for decentralized control strategies close to field devices.
Functional Advantages in Real Installations
Compact Modular Design
Optimized for high-density installations within small control cabinets or distributed I/O stations.
Reliable Discrete Switching
Provides stable ON/OFF output control for industrial loads.
Fast Response Time
Supports deterministic output updates aligned with PLC scan cycles.
Integrated Status Indication
Per-channel LED indicators simplify commissioning and troubleshooting.
VersaMax System Compatibility
Seamlessly integrates with VersaMax CPUs and network interface modules.
Technical FAQs
1. What type of loads can the IC200MDL730 control?
It is suitable for driving relays, solenoids, contactors, and indicator lamps within rated specifications.
2. Is the module protected against short circuits?
Yes, it includes internal protection mechanisms to guard against overload and short-circuit conditions.
3. What output type does it provide?
It delivers discrete (digital) outputs for industrial control applications.
4. How is the module powered?
Power is supplied through the VersaMax backplane interface.
5. Does it support hot insertion?
Hot swap capability depends on system configuration and installation practices.
6. What diagnostic features are available?
Channel-level LED indicators display output status and fault conditions.
7. Can it be used in distributed I/O networks?
Yes, it operates within distributed VersaMax I/O systems connected via network interface modules.
8. What is the switching response time?
Switching time aligns with controller scan rates and module design parameters.
9. Is isolation provided between outputs and logic circuits?
Yes, electrical isolation protects control electronics from field-side disturbances.
10. How is configuration handled?
Configuration is managed through the associated GE programming software within the VersaMax system.
