Product Overview
The ABB 086318-501 Memory Board is a compact storage module used within compatible ABB automation platforms to retain configuration, parameters, and system data. It functions as non-volatile storage that preserves critical control information, improving system resilience and maintainability.
Robust data retention and seamless integration with the host controller make it a valuable component in systems where configuration loss would impact uptime or require significant reconfiguration effort.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Memory Board / Storage Module |
| Model | 086318-501 |
| Platform | ABB Automation Systems |
| Primary Function | Non-volatile storage of configurations and parameters |
| Installation | Control panel / controller slot mounting |
| Operating Environment | Industrial automation cabinet settings |
| Dimensions (H × W × D) | 180 × 100 × 30 mm |
| Net Weight | 0.5 kg (approx. 1.10 lb) |
Function in Industrial Control Systems
The ABB 086318-501 Memory Board is a dedicated data storage module used in ABB automation and control platforms. It preserves configuration parameters, system state information, and program data essential for reliable operation of controllers, processors, or modular control units. Memory modules like this help ensure that critical control configurations are retained during power cycles, maintenance, or system resets.
Common usage scenarios include:
-
Storing configuration and logic settings in PLCs and modular controllers
-
Backup of control parameters for rapid restoration
-
System firmware and calibration storage for field devices
-
Preservation of log and historical data where supported
-
Reducing downtime during maintenance activities
Reliable memory retention supports faster system recovery and consistent behavior in automated environments.
Engineering Benefits and Practical Value
From a control systems engineering perspective, the memory board contributes to system stability and serviceability:
Persistent Data Retention
Ensures stored configuration and program data remain intact across power cycles or resets.
Rapid System Restoration
Facilitates fast reload of control logic and settings after maintenance events.
Secure Configuration Storage
Protects system programs and parameter sets from accidental loss or corruption.
Platform Integration Compatibility
Designed to interface seamlessly with the corresponding ABB controller or processor architecture.
Serviceable Form Factor
Compact board design makes installation and replacement straightforward.
Technical FAQs
-
What is the primary role of the 086318-501 Memory Board?
It stores and retains control system configuration, logic, and parameters for ABB automation modules.
-
Does it retain data during power loss?
Yes, its design ensures data persistence during power interruptions.
-
Is this a field-replaceable module?
Yes, the board is serviceable and can be replaced following platform guidelines.
-
Can it store firmware as well as configuration?
It supports storage of configuration and related system data; firmware storage depends on the host platform design.
-
Does installation require system downtime?
Installation practices vary; typically controlled shutdown is recommended for safe swapping.
-
Is it compatible with multiple controller models?
Compatibility depends on the specific ABB controller family and platform documentation.
-
Does it support redundant configurations?
Redundancy strategies depend on the overall system architecture and controller design, not solely the memory board.
-
How is data integrity verified?
System diagnostics and checksums help ensure valid storage and retrieval.
-
Can configuration updates be made online?
Updating configuration data is performed via system engineering tools while online support depends on the controller’s capabilities.
-
What environment is it designed for?
It is suitable for industrial control cabinet environments within the specified thermal and electrical conditions.
