Product Introduction
The Schneider Electric 140CFD03200 CableFast Terminal Block Module is engineered to streamline PLC cabinet wiring through structured cable integration. By bridging field devices and controller I/O modules using pre-engineered cable assemblies, it reduces installation labor and enhances signal management clarity.
Its robust construction and organized termination layout make it ideal for high-density industrial automation cabinets. The module contributes to improved reliability, maintainability, and professional panel design standards.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | CableFast Terminal Block Module |
| Model | 140CFD03200 |
| Platform Compatibility | Modicon Quantum PLC |
| Function | Field wiring termination interface |
| Mounting | Control cabinet installation |
| Application | Industrial automation systems |
| Package Dimensions (H × W × D) | 105 × 180 × 270 mm |
| Net Weight | 0.907 kg (approx. 2.00 lb) |
Deployment in Control Cabinet Architectures
The 140CFD03200 CableFast Terminal Block is designed to simplify field wiring and signal organization in Modicon Quantum automation systems. As part of Schneider Electric’s structured I/O connectivity ecosystem, this module provides a reliable transition point between field devices and control system I/O modules.
It is typically applied in:
-
PLC cabinet wiring standardization
-
High-density digital and analog I/O marshalling
-
Retrofit upgrades from legacy screw-terminal systems
-
OEM machine control panels
-
Process automation cabinets requiring pre-engineered cable solutions
The CableFast concept reduces wiring complexity and improves installation consistency across industrial projects.
Functional Advantages
From a panel builder’s perspective, the 140CFD03200 focuses on structured connectivity and reduced installation time.
Pre-Engineered Cable Interface
Designed for use with CableFast prefabricated cables, minimizing wiring errors.
Improved Installation Efficiency
Reduces manual termination work compared to traditional point-to-point wiring.
Enhanced Signal Organization
Supports cleaner cabinet layouts and simplified signal tracing.
Industrial-Grade Terminal Construction
Built for stable electrical contact in vibration-prone environments.
System Compatibility
Optimized for integration with Modicon Quantum PLC platforms.
Technical FAQs
-
What is the primary function of the 140CFD03200 module?
It provides a structured terminal interface between field wiring and PLC I/O modules.
-
Is it compatible with Modicon Quantum systems?
Yes, it is designed for integration with Quantum automation platforms.
-
Does it support both analog and digital signals?
Compatibility depends on the associated I/O module and cable configuration.
-
How does CableFast technology improve installation?
By using pre-terminated cables to reduce manual wiring and potential errors.
-
Can it be used in retrofit applications?
Yes, it is suitable for modernizing existing cabinets with structured wiring.
-
Does it provide signal isolation?
Isolation depends on the connected I/O module rather than the terminal block itself.
-
What type of mounting is used?
It is typically installed within a control cabinet on designated mounting hardware.
-
Is it suitable for high-vibration environments?
Yes, it is engineered for industrial conditions when properly installed.
-
How does it improve maintenance efficiency?
Structured wiring simplifies troubleshooting and signal identification.
-
Can multiple terminal blocks be installed in the same cabinet?
Yes, modular design supports scalable installation layouts.
