Product Overview
The GE IC695ALG600 RX3i Analog Input Module is a high-precision, industrial-grade analog input component designed for the RX3i Series of GE Automation & Controls PLCs. This module converts real-world analog signals, such as voltage, current, or thermocouple inputs, into digital data that the RX3i controller can process for accurate control and monitoring.
Built for reliability in industrial environments, the IC695ALG600 supports diverse sensor types and signal ranges, making it ideal for process automation, manufacturing, and utility applications. Its compact design and straightforward integration make it a versatile solution for both new installations and system expansions.
Technical Specifications
| Parameter | Specification |
|---|
| Module Type | Analog Input Module |
| Model Number | IC695ALG600 |
| System Compatibility | RX3i Series PLC |
| Input Channels | 8 differential or 16 single-ended channels |
| Input Range | ±10 V, 0–20 mA, 4–20 mA, thermocouples (type J, K, T, etc.) |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.1% Full Scale |
| Isolation | Channel-to-channel and channel-to-backplane isolation |
| Response Time | 2–5 ms per channel |
| Mounting | RX3i rack-mounted |
| Dimensions | 12.7 × 3.2 × 17.8 cm |
| Weight | Approx. 0.5 kg |
| Operating Temperature | 0–60°C |
| Environmental Rating | Industrial-grade, vibration and temperature tolerant |
| Diagnostic Indicators | Module status LEDs |
Typical Applications
The IC695ALG600 is widely used in applications requiring precise analog signal acquisition:
-
Process automation in chemical, petrochemical, and pharmaceutical plants
-
Factory automation and manufacturing systems
-
Temperature, pressure, and flow monitoring
-
Motor and drive control loops
-
Utility and energy management systems
-
Data acquisition from RTDs, thermocouples, and analog sensors
Its high resolution and accuracy make it suitable for critical control and monitoring processes where precise measurements are essential.
Technical FAQs
1. How many analog channels does the IC695ALG600 support?
It supports 8 differential or 16 single-ended channels.
2. What types of input signals are compatible?
Voltage, current, thermocouples, and RTDs.
3. What is the module’s resolution and accuracy?
16-bit resolution with ±0.1% full-scale accuracy.
4. Can it handle real-time control applications?
Yes, response times are 2–5 ms per channel.
5. Is it suitable for harsh industrial conditions?
Yes, designed for industrial temperature and vibration tolerance.
6. Does it provide isolation between channels?
Yes, channels are electrically isolated to protect against noise.
7. Can it integrate with other RX3i modules?
Yes, fully compatible within RX3i racks.
8. What is the mounting method?
Rack-mounted within RX3i PLC chassis.
9. Does it offer diagnostic capabilities?
Yes, module status LEDs provide operational feedback.
10. Which industries commonly use this module?
Process manufacturing, energy, utilities, and industrial automation sectors.
