Product Overview
The ABB Bailey IMASO01 Analog Output Slave Module is designed for high-precision analog signal delivery within the INFI 90 distributed control system. It converts digital control commands into accurate analog outputs for field devices, enabling precise operation of actuators, valves, and drives.
This module ensures reliable performance in mission-critical industrial environments, supporting both legacy system maintenance and modern process control requirements. Its robust design and compact form factor make it an ideal choice for maintaining process accuracy and system stability.
Technical Specifications
| Parameter | Specification |
|---|
| Module Type | Analog Output Slave Module |
| System Platform | INFI 90 |
| Output Channels | Up to 14 analog outputs |
| Output Signals | 1–5 VDC / 4–20 mA |
| Resolution | 10-bit D/A conversion |
| Output Accuracy | ≤0.15% (voltage), ≤0.25% (current) |
| Output Load | 750 Ω max (current), 22 kΩ min (voltage) |
| Power Supply | +5V, ±15V, +24V |
| Operating Temperature | 0°C to 70°C |
| Mounting | Standard INFI 90 rack |
Application Areas
The IMASO01 is ideal for industries and processes that require precise analog output control:
-
Power generation and distribution
-
Petrochemical and chemical processing
-
Process automation and production lines
-
Valve and actuator positioning
-
Motor drive control
-
Flow and pressure regulation systems
Its ability to translate digital control into stable analog output ensures accurate process control in diverse industrial settings.
Technical FAQs
1. What is the main function of the IMASO01?
It converts digital instructions from the DCS into analog output signals.
2. What signal types does it support?
1–5 VDC and 4–20 mA outputs.
3. How many output channels are available?
Up to 14 analog channels.
4. Can it control valves and actuators?
Yes, it is commonly used for precise actuator and valve control.
5. Is it compatible with legacy INFI 90 systems?
Yes, fully compatible.
6. Is it suitable for harsh industrial conditions?
Yes, it is designed for reliable operation in industrial environments.
7. What is its output accuracy?
Up to ±0.15% for voltage, ±0.25% for current.
8. Can it improve process precision?
Yes, by providing stable and accurate analog outputs.
9. Is installation straightforward?
Yes, standard rack mounting makes it easy to install.
10. Does it support real-time control?
Yes, enabling responsive process adjustments.
