Product Overview
The ABB Bailey IPCHS01 Power Module Chassis is a fundamental structural and power distribution component for Net 90 and Infi 90 distributed control systems. It provides a centralized mounting platform for processor, controller, and I/O modules, while supplying stable power and organized connectivity across the automation network.
Engineered for industrial reliability, the IPCHS01 chassis ensures optimal system performance by maintaining consistent power distribution, proper thermal management, and secure module alignment, making it ideal for mission-critical automation applications.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Power Module Chassis |
| Model Number | IPCHS01 |
| System Compatibility | Net 90 / Infi 90 DCS |
| Module Slots | 12 standard slots for processor and I/O modules |
| Input Power | 120/240 VAC (configurable) |
| Output Voltage | +5 VDC, +24 VDC (for modules) |
| Cooling | Natural convection or optional forced air |
| Mounting | Rack-mount or panel-mount configurations |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 85°C |
Applications
The IPCHS01 chassis is widely used in industrial automation setups requiring reliable module housing and power distribution:
-
Centralized control systems in power plants
-
Oil and gas process automation
-
Chemical and petrochemical process control
-
Water and wastewater treatment plants
-
Manufacturing process control systems
-
Distributed automation networks
Its structured design ensures easy integration of multiple control and I/O modules, supporting scalable and maintainable automation architectures.
Key Advantages
-
Provides stable and reliable power distribution to all installed modules
-
Facilitates organized module mounting and wiring management
-
Compatible with Net 90 and Infi 90 module families
-
Modular and expandable to accommodate growing system requirements
-
Supports industrial operating conditions with robust construction
-
Reduces system downtime through easy maintenance access
-
Ensures proper thermal management for long-term reliability
This chassis acts as the backbone of distributed control systems, keeping all modules powered, aligned, and operating efficiently.
Technical FAQs
1. What modules fit into the IPCHS01 chassis?
Processor, controller, and I/O modules compatible with Net 90 / Infi 90.
2. How many module slots does it provide?
12 standard module slots.
3. What input voltage does it accept?
120/240 VAC, configurable based on installation requirements.
4. What output voltages are provided?
+5 VDC and +24 VDC for module operation.
5. Can it be rack-mounted?
Yes, it supports rack or panel mounting.
6. How is cooling handled?
Via natural convection, with optional forced air.
7. Is it suitable for harsh industrial environments?
Yes, rated for 0°C to 55°C operation and robust industrial use.
8. Can the chassis be expanded?
Yes, additional compatible modules can be installed in available slots.
9. What is the weight of the chassis?
Approximately 12 kg.
10. How does it improve system reliability?
By centralizing power, module alignment, and thermal management.
