Product Overview
The ABB Bailey NRDO02 L700712 Relay Output Terminal Unit is designed as a robust interface module within the Net 90 and Infi 90 distributed control systems. It provides reliable relay-based digital output control for a variety of field devices, enabling seamless actuation of pumps, valves, motors, and other industrial equipment.
Engineered for durability and precision, the NRDO02 ensures consistent signal delivery even in harsh industrial conditions, making it an ideal choice for process-critical applications.
Technical Specifications
| Parameter | Specification |
|---|
| Module Type | Relay Output Terminal Unit |
| Model Number | NRDO02 L700712 |
| Output Type | Relay, Form C (SPDT) |
| Number of Outputs | 8 standard channels |
| Load Capacity | 2 A @ 250 VAC / 2 A @ 30 VDC per channel |
| Isolation | Optical isolation between logic and relay outputs |
| Response Time | Typically < 10 ms |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Mounting | Terminal block / rack-mounted |
Applications
The NRDO02 Relay Output Terminal Unit is commonly deployed in process automation environments requiring precise digital output control:
-
Pump and motor actuation in water treatment plants
-
Valve control in chemical and petrochemical industries
-
Alarm and indicator signaling in power generation
-
Process shutdown and interlock systems
-
Distributed control system expansions in manufacturing plants
-
Integration with field instrumentation and automation devices
Its reliability ensures accurate actuation for both safety-critical and standard control operations.
Advantages
-
High-reliability relay outputs for industrial actuators
-
Fast switching times suitable for process control
-
Optical isolation for noise immunity and signal protection
-
Compact, rack-mounted design for easy integration
-
Scalable and modular for large distributed control systems
-
Long service life under continuous industrial operation
-
Reduces wiring complexity by centralizing output terminals
This module provides a cost-effective solution for extending relay control throughout complex plant networks.
Technical FAQs
1. How many outputs does the NRDO02 provide?
It provides 8 relay outputs.
2. What type of relay is used?
SPDT (Form C) relays are used for each channel.
3. What is the maximum load per channel?
2 A at 250 VAC or 2 A at 30 VDC per output.
4. Can it operate in high-temperature environments?
Yes, rated for 0°C to 60°C operation.
5. How is the module mounted?
It mounts to terminal racks within Net 90/Infi 90 systems.
6. Is electrical isolation provided?
Yes, optical isolation separates logic and relay outputs.
7. What is the typical response time?
Switching occurs in less than 10 milliseconds.
8. Can it control multiple types of devices?
Yes, suitable for valves, motors, alarms, and indicators.
9. Is it compatible with Net 90 and Infi 90 systems?
Yes, fully compatible with these distributed control systems.
10. How does it benefit industrial operations?
It ensures reliable, modular relay output control with simplified wiring.
