Name: ABB Bailey IMRAE12 Isolated Analog Input Module
Brand: Hima DCS Modules
SKU: 5156
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Hima DCS Modules
Item No.:IMRAE12
Product Origin:USA
Product Dimensions:180 mm *51 mm* 25 mm
Product Weight:0.45 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The ABB Bailey IMRAE12 Isolated Analog Input Module is engineered to provide precise, reliable analog signal acquisition in demanding industrial environments. Built for the INFI‑90 distributed control system, this module ensures accurate measurement and isolation of multiple analog inputs, safeguarding system integrity while enhancing signal quality. Its design combines industrial robustness with easy integration, making it an essential component for process monitoring and control.

Technical Specifications

Feature	Specification
Model	IMRAE12
Type	Isolated Analog Input Module
Number of Channels	12 analog inputs
Input Signal Types	4–20 mA, 0–10 V, thermocouples, RTDs
Isolation	Channel-to-channel and channel-to-backplane isolation
Accuracy	±0.05 % of full scale
Operating Temperature	0 °C to 55 °C
Storage Temperature	–25 °C to 70 °C
Humidity	5–95 % non-condensing
Mounting	DIN rail or rack insertable

Applications

The IMRAE12 module is ideal for industrial process control where accurate and isolated analog measurement is critical:

Chemical and petrochemical process monitoring
Power generation analog data acquisition
Refineries and oil & gas pipeline control
Manufacturing automation requiring precise temperature or flow readings
Distributed control systems with mixed analog signal sources

Its isolated design minimizes interference and ensures high-fidelity data acquisition in electrically noisy environments.

Advantages

The ABB Bailey IMRAE12 offers significant benefits for system integrators and operators:

High Accuracy: Maintains precise analog readings across all channels.
Channel Isolation: Prevents cross-talk and protects system integrity.
Versatile Inputs: Supports voltage, current, thermocouples, and RTDs.
Compact and Durable: Optimized for installation in dense racks or cabinets.
Reliable Operation: Performs consistently under industrial temperature and humidity conditions.

This combination of accuracy, reliability, and integration flexibility makes the IMRAE12 a key module for critical process control.

Technical FAQs

How many analog channels does the IMRAE12 support?
It supports 12 fully isolated analog input channels.
Which types of signals can it measure?
Voltage (0–10 V), current (4–20 mA), thermocouples, and RTDs.
What is the isolation level?
Each channel is isolated from other channels and the backplane.
What is the module’s measurement accuracy?
±0.05 % of full scale.
What operating temperature range does it support?
0 °C to 55 °C.
Can it be mounted on a DIN rail?
Yes, it supports DIN rail and rack installation.
Is the module suitable for high-humidity environments?
Yes, it operates in 5–95 % non-condensing humidity.
Does it support hot-swapping?
Hot-swapping depends on the host system; consult system guidelines.
Can it measure thermocouples and RTDs simultaneously?
Yes, channels are configurable for different sensor types.
Is it compatible with legacy INFI‑90 controllers?
Yes, fully compatible with standard INFI‑90 control systems.
