The GE DS200SHVIG1BFC is a specialized PCB circuit board used within GE industrial drive systems, particularly in sections where signal interfacing, gating control, or voltage-related processing is required. Its design supports high-reliability operation inside power-electronic environments, where stable logic communication and robust PCB construction are essential.
This document outlines the board’s characteristics from a practical engineering viewpoint, offering a concise yet technically grounded reference for maintenance, planning, and system integration tasks.
Technical Specifications
| Parameter | Estimated Specification |
|---|---|
| Module Type | PCB Circuit Board |
| Model | DS200SHVIG1BFC |
| Function | Internal logic / interface circuitry within GE industrial drive systems |
| Board Layout | Multi-layer industrial PCB with reinforced connectors |
| Mounting Style | Chassis-mount inside GE drive cabinet |
| Operating Environment | High-electrical-noise industrial applications |
| Estimated Dimensions (H × W × D) | 235 × 160 × 32 mm |
| Estimated Weight | ≈ 1.1 kg |
| Material Composition | High-temperature PCB laminate, plated copper, protective coating |
| Connector Types | Mixed pin headers, signal connectors, board-level interface terminals |
