Product Overview
The Schneider Electric ABL7RP2403 Switching Power Supply is a reliable industrial power module designed to deliver stable DC power for automation and control systems. Part of Schneider’s PHASEO™ ABL7RP series, this unit provides 24 V DC at 3 A output from a universal AC input, making it suitable for PLCs, sensors, relays, and other devices requiring clean, consistent power.
Compact and efficient, the ABL7RP2403 is ideal for installation in control panels where space is limited but a dependable 24 V supply is essential. Its regulated switching design ensures high efficiency and resilience in industrial environments.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Switching Power Supply |
| Model Number | ABL7RP2403 |
| Input Voltage | 100 – 240 VAC (50 / 60 Hz) |
| Output Voltage | 24 V DC |
| Output Current | 3 A |
| Output Power | ~72 W |
| Type of Regulation | Switch Mode Power Supply (SMPS) |
| Protection | Overload / Short‑Circuit Protection |
| Status Indicator | Output LED |
| Mounting Type | DIN Rail or Panel |
| Operating Temperature | Industrial Range |
| Storage Temperature | Industrial Range |
| Insulation | Industrial‑grade insulation |
Applications
The ABL7RP2403 is widely used wherever stable 24 V DC power is required:
-
PLC racks and control cabinets
-
Industrial sensors and actuators
-
Relays, timers, and field devices
-
Machine logic and power distribution
-
Conveyor and material handling systems
Its regulated output ensures sensitive control modules operate without voltage fluctuations.
Advantages
-
Universal AC Input Range – Supports 100–240 VAC for global compatibility
-
Stable DC Output – Provides consistent 24 V DC under load
-
Compact Design – Ideal for panel-mounted control systems with limited space
-
Efficient SMPS Architecture – High efficiency for industrial uptime
-
Visual Output Status – LED indicator simplifies diagnostics
-
Reliable Protection – Built-in safeguards against overload and short-circuits
These features provide confidence for system designers and maintenance teams in industrial applications.
Technical FAQs
1. What output voltage does the ABL7RP2403 provide?
24 V DC.
2. What is the maximum output current?
3 A continuous.
3. What AC input range is supported?
100–240 VAC, 50/60 Hz.
4. Can this power supply be mounted on a DIN rail?
Yes, DIN rail or panel mounting is supported.
5. Does it include overload protection?
Yes, it has built-in overload and short-circuit protection.
6. Is there a status indicator?
Yes, an LED shows output status.
7. What is the approximate power rating?
Approximately 72 W (24 V × 3 A).
8. Is it suitable for global use?
Yes, the wide AC input accommodates international voltages.
9. What environments is it suitable for?
Industrial control cabinets and automation systems.
10. Is this part discontinued?
Some suppliers list it as legacy, but it is still widely used.
