Product Overview
The Schneider Electric ABE7S16E2M0 Solid‑State Output Relay Base is a high‑performance interface module designed for industrial automation systems demanding silent, wear‑free switching. As part of the Telefast ABE7 series, this base supports solid‑state relay (SSR) output modules, offering superior electrical isolation, long life, and fast switching without mechanical contacts.
Engineered for reliable operation in tough industrial environments, the ABE7S16E2M0 combines 16 solid‑state output channels with soldered connections to ensure robust, maintenance‑free signal distribution. Its compact form factor and clear layout simplify wiring, improve cabinet organization, and support efficient installation.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Solid‑State Output Relay Base |
| Channels | 16 Solid‑State Outputs |
| Terminals | Soldered Connections |
| Output Type | Solid‑State (SSR Compatible) |
| Rated Output Voltage | 24…250 V AC / DC |
| Maximum Load Current | 2 A per Channel |
| Control Voltage | 19…30 V DC |
| Insulation Voltage | 2000 V |
| Protection Rating | IP20 |
| Operating Temperature | -5°C to 60°C |
| Storage Temperature | -40°C to 80°C |
| Mounting | DIN Rail (35 mm) / Panel Mount |
| LED Indicators | Channel Status |
| Installation Category | II |
Applications
The ABE7S16E2M0 is ideal for applications where silent operation, fast switching, and high‑cycle reliability are critical:
-
Industrial machine automation
-
Conveyor and motion control systems
-
Batch process controls
-
HVAC and building automation
-
High‑frequency switching applications
-
Signal logic and sequencing systems
Its solid‑state architecture allows for lower electrical noise and extended life compared to electromechanical relays.
Advantages
-
Contact‑Free Switching – SSR compatibility provides silent and wear‑free operation
-
High‑Density Outputs – 16 channels in a compact package
-
Soldered Reliability – Permanent connections reduce service needs
-
Wide Voltage Support – Handles 24–250 V AC/DC loads
-
Clear Status Indication – Integrated LEDs per channel
-
Flexible Mounting – DIN rail or panel installation
-
Industrial Safety – 2000 V insulation rating
-
Optimized for High‑Cycle Use – Excellent for frequent switching environments
This combination of features makes the ABE7S16E2M0 a dependable choice for automated systems that require robust, fast, and silent output control.
Technical FAQs
1. What is the ABE7S16E2M0 used for?
It provides a base for 16 solid‑state output channels, enabling contact‑free switching.
2. How many output channels does it have?
16 solid‑state outputs.
3. What type of outputs does it support?
Solid‑state (SSR compatible) outputs for silent, reliable switching.
4. What load voltage range does it handle?
24–250 V AC/DC.
5. What is the maximum current per channel?
2 A per channel.
6. Are LEDs included for status indication?
Yes, each channel includes an LED status indicator.
7. Can it be mounted on a DIN rail?
Yes, it supports 35 mm DIN rail and panel mounting.
8. What is the insulation rating?
2000 V for industrial safety.
9. What is the operating temperature range?
-5°C to 60°C.
10. Is this suitable for high‑cycle automation?
Yes, solid‑state outputs are ideal for frequent switching and long life.
