Introduction
The ABB 87TS01 is a modular coupling and communication interface engineered for use in industrial control and distributed control system installations. It functions as a reliable signal coupling interface between external systems — such as operator stations, computers, or secondary controllers — and the internal bus networks of ABB automation platforms. Designed for robust industrial operation, it maintains stable data exchange even in electrically noisy environments.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | ABB |
| Model | 87TS01 |
| Part Number(s) | 87TS01, variants include 87TS01‑1551, GJR2368900R1551 |
| Product Type | Coupling / Communication Module |
| Compatibility | ABB PROCONTROL, Advant MOD 300, Advant OCS, related automation systems |
| Interface | Serial (RS232c / RS422) & internal station bus |
| Power Supply | Nominal +24 V DC |
| Operating Temperature | –20 °C … +60 °C |
| Storage Temperature | –40 °C … +85 °C |
| Mounting | Plug‑in rack mounting |
| Dimensions | Compact module form factor |
| Weight | Approx. 0.5 kg |
| Application | Signal coupling and communication interface |
| Protection/Features | Supports electrical isolation, maintains signal integrity |
