Emerson KJ4006X1-BP1 DeltaV 40-pin Mass Terminal Block

Brand:Emerson Module
Item No.:KJ4006X1-BP1
Product Origin:USA
Product Dimensions:125 × 35 × 30 mm
Product Weight:0.2kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

KJ4006X1-BP1 1KJ4006X1-BP1 2KJ4006X1-BP1 3KJ4006X1-BP1 4

Product Introduction

The Emerson KJ4006X1‑BP1 DeltaV 40‑Pin Mass Terminal Block is a highly reliable connection interface designed for use within Emerson’s DeltaV automation systems. It provides a centralized termination point for field wiring, enabling secure and efficient routing of signal and power lines between field devices (sensors, actuators, transmitters) and I/O cards. Built for industrial environments, this terminal block helps engineers maintain clean wiring layouts, simplifies panel installation, and supports stable, trouble‑free system operation.

Technical Specifications

SpecificationDetails
Product Type40‑Pin Mass Terminal Block
Model NumberKJ4006X1‑BP1
Compatible SystemEmerson DeltaV S‑Series Digital Automation
Number of Pins40
Field Power Rating30 V DC @ 3.2 A per pin (typical)
Contact TypeMass/cluster termination, screw‑clamp style
Terminal Block KeyingRotary key position matched to I/O card
Environmental Rating−40 °C to +70 °C, industrial vibration & shock design
Ambient ConditionsISA‑S71.04 Class G3 contaminants
MountingRack/cabinet mount (panel)


Typical Use Cases

The KJ4006X1‑BP1 is widely used as a field wiring interface in distributed control and process automation systems:

  • Centralizing field terminal connections in control cabinets

  • Linking multiple discrete and analog signals to DeltaV I/O cards

  • Simplifying panel layouts and reducing wiring congestion

  • Terminating multi‑wire harnesses for sensors and actuators

  • Supporting service and maintenance with clear, organized terminal points

By consolidating connections in a mass terminal block, system designers and technicians gain faster installation and simplified troubleshooting.


Benefits and Key Features

  • High‑Density Wiring Support: Handles large bundles of field connections in a compact footprint.

  • Industry‑Tough Design: Rated for industrial temperature, shock, vibration, and airborne contaminants.

  • Rotary Keying System: Ensures correct terminal block orientation matched to specific I/O cards.

  • Secure Termination: Screw‑clamp contacts maintain signal integrity and resist loosening under vibration.

  • DeltaV Compatibility: Seamless integration with Emerson DeltaV S‑Series hardware ensures consistency across automation installations.

These features make it an efficient and practical interface for control system panels in process, power, and manufacturing environments.


Technical FAQs

  1. What is the primary function of this terminal block?
    Serves as the mass connection point for field wiring between field devices and DeltaV I/O modules.

  2. How many pins does it provide?
    This block offers 40 individual connection points.

  3. What voltage and current levels does it support?
    Each connection is generally rated for 30 V DC at up to 3.2 A.

  4. Is it suitable for harsh industrial environments?
    Yes — ambient operating range and rugged design support typical plant conditions.

  5. Does it have keying features?
    Yes — a rotary keying system helps ensure the correct terminal block is matched to the intended I/O card.

  6. Can this block be replaced or maintained easily?
    The modular design and clear pin layout support straightforward replacement and servicing.

  7. What installation environment is recommended?
    Cabinet or rack mounting within industrial control panels.

  8. Is shielding required for this block?
    While the block itself doesn’t provide shielding, matching cable and grounding practices should be used for noise-sensitive signals.

  9. Can this block work with both discrete and analog I/O?
    Yes — its mass connection layout supports mixed signal types when paired with the correct DeltaV I/O module.

  10. Does it require special tools to terminate wiring?
    Standard industrial screwdrivers and wiring tools are typically sufficient.
