Introduction
The ABB Bailey PHBAIN2200S200 Analog Input Base provides reliable analog data capture and enhanced signal conditioning for demanding industrial environments. Designed for modular distributed I/O systems, this base supports a broad array of analog sources and scales easily within large architectures. With its robust construction and adaptive configuration, it offers plant engineers precise measurement, strong environmental tolerance, and optimized performance for critical process control applications.
Whether handling temperature inputs from thermocouples or scaling current loops from industrial transmitters, the PHBAIN2200S200 is built to support sustained plant operation and accurate system feedback.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Name | ABB Bailey PHBAIN2200S200 |
| Module Type | Analog Input Base |
| Input Channels | Up to 16 Analog Inputs |
| Supported Signals | 4–20 mA, ±10 VDC, Thermocouples, RTDs |
| ADC Resolution | 16-bit |
| Signal Conditioning | Differential input with precision filtering |
| Operating Temperature | -40 °C to +70 °C / -40 °F to +158 °F |
| Storage Temperature | -40 °C to +85 °C / -40 °F to +185 °F |
| Humidity Tolerance | 5 % to 95 % non-condensing |
| Mounting Options | DIN-rail or rack compatible |
| Weight (Approx.) | 0.68 lb / 0.31 kg |
| Dimensions (H × W × D) | 1.8 × 4.2 × 6.3 inches |
| Dimensions (Metric) | 46 × 107 × 160 mm |
