Applications
The expanded battery module is ideal in industrial control systems where power interruptions must not compromise retained logic or timestamp data. Typical use cases include:
-
Real-Time Clock Support: Maintaining accurate time data during power loss
-
Data Retention: Preserving ladder logic and register contents that require backup power
-
Controlled Restart: Supporting orderly PLC restart with minimal data loss after outages
-
Critical Process Systems: Power-sensitive systems in utilities, manufacturing, and infrastructure
By enhancing backup endurance, this module strengthens system resilience against brief or extended power disturbances.
Advantages
-
Extended Backup Life: Provides longer retention time for PLC memory and real-time clock compared to standard batteries
-
Maintenance-Free Design: Sealed battery reduces service needs and eliminates frequent replacement cycles
-
System Compatibility: Works with Series 90-30 and Rx3i PLC architectures
-
Supports Critical Data Integrity: Reduces risk of losing time, configuration, or state data after power loss
-
Compact and Reliable: Small footprint and rugged construction suitable for industrial cabinets
These features help ensure that essential system data and timestamps are preserved, even under variable power conditions.
Technical FAQs
-
What is the main purpose of the IC693ACC400?
It provides extended backup battery power to preserve PLC memory and real-time clock during power interruptions.
-
Which PLC platforms is it compatible with?
GE Fanuc Series 90-30 and Rx3i systems.
-
Does it replace the standard battery?
It expands the backup capacity beyond the standard onboard battery configuration.
-
Is it rechargeable?
Yes — the module uses a sealed, rechargeable battery designed for industrial systems.
-
Can it maintain logic retention during extended outages?
Yes — it extends retention time compared to factory-standard batteries.
-
Does it require regular maintenance?
No — the sealed design minimizes maintenance.
-
Where is it installed?
Inside a control cabinet or PLC rack in proximity to the power supply module.
-
Will it interfere with normal PLC operation?
No — it supports backup power without affecting live operation.
-
Can it be added to existing systems?
Yes — it can be retrofitted to compatible Series 90-30 and Rx3i systems.
-
Is it suitable for safety-critical applications?
Yes — maintaining data and clock integrity is crucial in many safety and process control installations.
