Introduction
The 3601TN is a digital‑output module intended for use within safety‑rated control systems built on the Triconex platform. Its role is to deliver discrete digital signals from the safety/control logic to field devices such as valves, alarms, or contactors. Designed with modularity and reliability in mind, 3601TN offers deterministic output behavior suitable for industrial environments where safety integrity and redundancy are critical. This description assumes typical module characteristics and provides a working reference for planning and integration.
Technical Specifications
| Parameter | Specification / Note |
|---|---|
| Module Type | Digital Output Module |
| Model | 3601TN |
| Output Channels | 16 discrete digital outputs (typical configuration assumption) |
| Output Signal Type | 24 V DC discrete outputs or relay/contact‑style discrete lines (depending on wiring/load) |
| Isolation | Channel-to-backplane isolation to maintain signal integrity and safety separation |
| Redundancy Compatibility | Suitable for redundant or safety-rated Triconex system architectures |
| Power Supply | Powered via system backplane; no external auxiliary power required under nominal load |
| Environment Rating | Industrial standard: designed for tolerance to vibration, EMI, shock, and typical process‑plant ambient conditions |
| Estimated Dimensions | 175 × 45 × 125 mm (H × W × D) |
| Estimated Weight | ≈ 0.6 kg |
| Mounting Method | Rack-mounted within control chassis compatible with Triconex-style systems |
