ABB 70BA01C-S HESG447260R2 Bus End Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB 70BA01C-S HESG447260R2 Bus End Module

Name: ABB 70BA01C-S HESG447260R2 Bus End Module
Brand: ABB PLC
SKU: 481
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:70BA01C-S HESG447260R2
Product Origin:Switzerland
Product Dimensions:80 mm × 35 mm × 150 mm
Product Weight:0.18KG
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction — Reliable Termination for ABB DCS Bus Systems

The ABB 70BA01C-S HESG447260R2 Bus End Module is designed to provide secure and reliable termination for ABB Distributed Control System (DCS) bus networks. This module ensures proper signal integrity, stable communication, and protection at the end of digital and analog I/O bus lines. Compact and durable, the bus end module is essential for maintaining system stability and minimizing communication errors in complex industrial automation environments.

Technical Specifications — Performance & Physical Profile

Specification	Description
Module Type	Bus End Module
Model / Part Number	70BA01C-S / HESG447260R2
Function	Provides termination for ABB DCS I/O bus systems
Bus Type	ABB proprietary digital/analog I/O bus
Termination	Ensures proper signal integrity at the end of bus lines
Isolation	Provides electrical isolation between bus and system components
Power Supply	Supplied via backplane bus
Operating Temperature Range	–20 °C to +60 °C
Dimensions	80 mm × 35 mm × 150 mm
Weight	~0.18 kg
Mounting	DIN rail or ABB modular rack system
Compliance / Certifications	CE, UL, RoHS compliant

Applications — Key Use Cases

Termination of ABB DCS digital and analog I/O bus networks
Maintaining signal integrity in large-scale control cabinets
Reducing communication errors and preventing bus reflections
Ensuring stable operation in harsh industrial environments
Essential for expansions or replacement of existing bus systems
Integration in chemical, water treatment, power, and manufacturing plants

Advantages — Why Choose the 70BA01C-S HESG447260R2

Ensures proper bus termination for stable communication
Compact and lightweight design for efficient cabinet integration
DIN rail or modular rack mounting for easy installation
Electrical isolation improves system reliability and protects sensitive components
Wide operating temperature range suitable for industrial environments
Compliance with CE, UL, and RoHS ensures safety and regulatory alignment

Technical FAQs — 10 Key Questions

What is the main function of this module?
- To provide proper termination for ABB DCS bus systems.
What bus types are supported?
- ABB proprietary digital and analog I/O bus.
Does the module provide electrical isolation?
- Yes, isolation between bus and system components is included.
What is the operating temperature range?
- –20 °C to +60 °C.
How is the module powered?
- Via the backplane bus.
What are the module dimensions and weight?
- 80 mm × 35 mm × 150 mm; ~0.18 kg.
What mounting options are available?
- DIN rail or ABB modular rack mounting.
Is it suitable for industrial environments?
- Yes, designed for harsh industrial conditions.
Can it be used for expanding existing bus networks?
- Yes, ideal for expansion and replacement applications.
What standards does it comply with?
- CE, UL, and RoHS compliant.
