Introduction — Flexible, High‑Density Digital Output for ABB DCS & Control Systems
The ABB 70AB02A‑E / GJR2313600R0003 module is a versatile digital output module engineered to provide reliable, isolated switching of field devices in industrial automation applications. With up to 16 discrete output channels, this module offers engineers flexibility and high channel density — ideal for complex control systems, distributed control systems (DCS), or PLC‑based automation racks. Its compact form factor and modular design simplify installation and maintenance while ensuring robust performance under harsh industrial conditions.
Technical Specifications — Performance & Physical Profile
| Specification | Description |
|---|---|
| Module Type | Digital Output Module (Discrete / Relay Output) |
| Model / Part Number | 70AB02A‑E / GJR2313600R0003 |
| Number of Output Channels | 16 discrete outputs (relay-type, N.O. / N.C.) |
| Operating Voltage | 24 V DC (nominal system supply) |
| Max. Load Current per Output | 2 A per channel |
| Output Type | Relay outputs (NO/NC) — suitable for AC or DC loads depending on wiring and relay specification |
| Isolation | Galvanic isolation between inputs/bus and outputs, ensuring electrical safety and noise immunity |
| Power Consumption | ~3 W module consumption |
| Mounting | DIN‑rail compatible or ABB modular rack/chassis |
| Dimensions | ~100 mm × 120 mm × 75 mm |
| Weight | ~0.20 kg |
| Operating Temperature Range | –20 °C to +60 °C |
| Compliance / Certifications | CE, UL, RoHS compliant |
