GE Fanuc IC694ALG442 Analog Mixing Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

GE Fanuc IC694ALG442 Analog Mixing Module

Name: GE Fanuc IC694ALG442 Analog Mixing Module
Brand: GE Fanuc PLC
SKU: 4382
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:GE Fanuc PLC
Item No.:IC694ALG442
Product Origin:USA
Product Dimensions:101*133*76mm
Product Weight:0.45kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The IC694ALG442 Analog Mixing Module is a purpose-built signal processing component designed for advanced analog control in modular PLC systems. Engineered to blend and scale multiple analog inputs into consolidated output signals, this module enables refined signal management for complex process applications. With a focus on precision, reliability, and industrial durability, the IC694ALG442 helps automation systems translate raw sensor data into meaningful control variables.

Technical Specifications

Specification	Details
Model	IC694ALG442
Module Type	Analog Mixing Module
Input Channels	4 analog inputs
Output Channels	2 mixed analog outputs
Supported Signal Types	Voltage and Current
Input Ranges	±10 V, 0–10 V, 0–20 mA, 4–20 mA
Output Ranges	0–10 V, 4–20 mA
Resolution	12-bit processing
Mixing Functions	Scaling, summing, averaging
Backplane Power Consumption	Designed for low system load
Isolation	Input/output isolation from backplane
Installation	Slot-mounted in modular PLC rack

Applications

The IC694ALG442 excels in automation environments where dynamic signal integration is required:

Process control systems aggregating sensor data for single-control loops
Analog signal blending in advanced motion and position control
Manufacturing environments with composite sensor inputs
Energy systems requiring harmonized analog feedback
OEM machinery with mixed analog input sources

By consolidating and shaping analog signals before logic processing, it simplifies control strategies and enhances data quality.

Advantages

Multi-Signal Handling: Efficiently combines and scales multiple inputs into meaningful outputs.
High-Resolution Processing: 12-bit precision ensures accurate signal transformation.
Flexible Configuration: Supports both voltage and current inputs and outputs.
Industrial Durability: Designed for sustained performance in control cabinets.
Simplifies Logic Design: Offloads mixing functions from central controllers for cleaner program logic.

Technical FAQs

What does the IC694ALG442 do?
It mixes and scales multiple analog inputs into optimized output signals.
How many inputs and outputs does it support?
It has 4 analog input channels and 2 mixed analog output channels.
Can it handle both voltage and current signals?
Yes, it supports standard industrial voltage and current ranges.
Is channel isolation provided?
Inputs and outputs are isolated from the backplane for improved signal integrity.
What types of mixing functions are available?
Common functions include scaling, summing, and averaging of input signals.
What is the resolution of the analog conversion?
Signal processing is performed at 12-bit resolution.
Does it require calibration?
Field calibration is generally not required under typical operating conditions.
Is this module suitable for continuous industrial use?
Yes, it is designed for 24/7 industrial operation.
Where is this module installed?
It fits into a compatible PLC rack mounted on the universal backplane.
Can it reduce controller program complexity?
Yes, by handling analog mixing internally, it simplifies the main control logic.
