ABB GV C704 AE01 3BHB003230R0101 Integrated Gate-Commuted Thyristor (IGCT) Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB GV C704 AE01 3BHB003230R0101 Integrated Gate-Commuted Thyristor (IGCT) Module

Name: ABB GV C704 AE01 3BHB003230R0101 Integrated Gate-Commuted Thyristor (IGCT) Module
Brand: ABB PLC
SKU: 4247
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:GV C704 AE01 3BHB003230R0101
Product Origin:Sweden
Product Dimensions:140 × 140 × 40 mm
Product Weight:1.6kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The ABB GV C704 AE01 3BHB003230R0101 Integrated Gate-Commuted Thyristor (IGCT) Module represents ABB’s advanced power semiconductor technology, designed for high-power, high-efficiency industrial applications. Combining the robustness of traditional thyristors with the fast switching capability of transistors, this IGCT module delivers exceptional performance in demanding environments where precise power control, thermal stability, and long service life are essential. It is widely recognized for its reliability in mission-critical drive and power conversion systems.

Technical Specifications

Specification	Details
Model	GV C704 AE01
ABB Part Number	3BHB003230R0101
Module Type	Integrated Gate-Commuted Thyristor (IGCT)
Rated Blocking Voltage	4.5 kV class
Rated Turn-Off Current	High-current industrial grade
Gate Unit Integration	Integrated gate control interface
Cooling Method	Press-pack design, liquid or forced air cooling
Operating Temperature	-40 °C to +125 °C (junction)
Mounting Type	Press-pack / clamped assembly
Dimensions (Approx.)	140 × 140 × 40 mm
Weight	approx. 1.6 kg

Applications

The ABB GV C704 AE01 IGCT module is purpose-built for high-power industrial systems where efficiency and reliability are critical, including:

Medium-voltage and high-power motor drives
Industrial inverters and converters
Traction and transportation power systems
Grid-connected power conversion equipment
Heavy industrial processes such as rolling mills, compressors, and pumps

Its stable electrical characteristics make it a preferred solution for continuous and cyclic load applications.

Advantages

High Power Density: Delivers exceptional current handling in a compact press-pack design.
Fast Switching Performance: Enables efficient power conversion with reduced losses.
Thermal Stability: Optimized for excellent heat dissipation and long operational life.
Industrial Reliability: Designed for harsh environments and continuous duty cycles.
Proven ABB Technology: Built on ABB’s extensive expertise in high-power semiconductors.

Technical FAQs (10)

What is an IGCT module?
An IGCT combines the low conduction losses of a thyristor with fast turn-off capability similar to a transistor.
What voltage class does this module belong to?
It is designed for high-voltage industrial applications in the 4.5 kV class.
Is this module suitable for medium-voltage drives?
Yes, it is commonly used in medium-voltage motor drive systems.
How is the module cooled?
It supports efficient cooling through press-pack mounting with air or liquid cooling solutions.
Does it include gate control integration?
The module is designed to interface seamlessly with ABB gate drive units.
What makes IGCTs more reliable than traditional IGBTs?
IGCTs offer lower conduction losses and superior thermal robustness in high-power applications.
Can it handle continuous high current operation?
Yes, it is engineered for continuous and heavy-duty current loads.
Is the module suitable for regenerative systems?
Yes, it performs well in bidirectional and regenerative power conversion systems.
What type of mounting is required?
A press-pack clamped assembly is required to ensure optimal electrical and thermal contact.
Is this module commonly used as a replacement part?
Yes, it is widely used for maintenance and upgrades in ABB high-power drive systems.
