Yokogawa AAI543-H00/K4S00 Analog Output Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Yokogawa AAI543-H00/K4S00 Analog Output Module

Name: Yokogawa AAI543-H00/K4S00 Analog Output Module
Brand: Yokogawa Electric
SKU: 417
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.: AAI543-H00/K4S00
Product Origin:
Product Dimensions:130 mm × 25 mm × 180 mm
Product Weight:0.35KG
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Yokogawa AAI543-H00/K4S00 Analog Output Module

Introduction — Flexible HART-Enabled Analog Output for Industrial Automation

The Yokogawa AAI543-H00/K4S00 Analog Output Module is a high-performance, HART-enabled solution engineered for distributed control systems (DCS). With 16 isolated 4–20 mA output channels, it delivers precise control of valves, actuators, and other field devices. The K4S00 variant features a KS-Cable interface with enhanced surge protection and secure connections, making it ideal for complex industrial environments where reliability, flexibility, and long-term performance are essential.

Technical Specifications — Performance & Physical Profile

Specification	Description
Module Type	16-channel Isolated Analog Output Module (HART-enabled, K4S00 variant)
Output Signal	4–20 mA DC per channel
Number of Channels	16 isolated outputs
Load Resistance	0–750 Ω per channel
Open Circuit Detection	<0.65 mA
Accuracy	±48 µA (~0.1% of span)
Update Rate	~10 ms per channel
Isolation Voltage	1500 V AC (output-to-system)
Power Supply	24 V DC nominal
Operating Temperature	–25°C to +75°C
Dimensions	130 mm × 25 mm × 180 mm
Weight	~0.35 kg
Communication Protocol	HART (two-way digital communication over analog loops)

Applications — Where the AAI543-H00/K4S00 Excels

Driving analog loops for valves, actuators, and pumps in chemical, petrochemical, and power industries
Integration into DCS for precise process control and redundancy
Enabling HART communication for device diagnostics, remote parameter tuning, and predictive maintenance
Implementing redundant analog output configurations for critical systems
Simplifying wiring and improving connection reliability in retrofits or new installations
Maintaining stable outputs in environments with electrical noise and interference

Advantages — Key Benefits

HART-enabled outputs provide remote monitoring, diagnostics, and configuration
16 isolated channels maximize output density while conserving rack space
Enhanced KS-Cable interface ensures secure and reliable wiring connections
Surge-protected design guards outputs against electrical transients
Fast response (~10 ms per channel) enables real-time process control
Compact and durable for harsh industrial environments
Wide operating temperature range ensures consistent performance

Technical FAQs — 10 Common Questions

What type of signal does the module output?
- 4–20 mA DC per channel with HART communication.
How many output channels are available?
- 16 isolated channels.
What is the maximum load resistance per channel?
- Up to 750 Ω.
Does it detect open circuits?
- Yes, currents below 0.65 mA are flagged.
What is the update rate per channel?
- Approximately 10 ms.
Can it be used in redundant configurations?
- Yes, redundancy is supported.
What is the output accuracy?
- ±48 µA (~0.1% of span).
What power supply does it require?
- 24 V DC nominal.
Is it suitable for harsh industrial conditions?
- Yes, operating range –25°C to +75°C.
What are the advantages of the K4S00 variant?
- Enhanced KS-Cable interface with surge protection for secure and reliable wiring.
