Technical FAQs — Practical Answers for Engineers

1. Is the probe compatible with all 3300 XL drivers?
   Yes, as long as driver and extension cable lengths match the probe code.

2. Can the probe withstand high temperatures?
   It is rated for up to +177°C, suitable for most turbine bearing housings.

3. Does cable length affect calibration?
   Yes — the system must use a matched probe, cable, and driver set.

4. What shaft materials are acceptable?
   Conductive metals, with AISI 4140 being the calibration reference.

5. Is the probe interchangeable with older 7200 series probes?
   Not directly; 3300 XL systems use different performance specifications.

6. Can the probe be used in hazardous areas?
   Hazardous-area certification depends on the overall transducer system.

7. How is the probe gap adjusted?
   By setting the DC voltage output of the completed transducer system.

8. Does the probe require periodic recalibration?
   No recalibration of the probe itself, only system verification as required.

9. Can it measure thrust position?
   Yes, when used with appropriate drivers and mounting.

10. Is EMI shielding included?
    Yes — the probe and cable assembly are designed to resist electromagnetic interference.
