ABB DSQC236T YB560103-CE Servo Drive Control Board

Brand:ABB PLC
Item No.:DSQC236T YB560103-CE
Product Origin:Sweden
Product Dimensions:250 mm × 24 mm × 240 mm
Product Weight:0.42kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact

DSQC236T YB560103-CE 3DSQC236T YB560103-CE 2DSQC236T YB560103-CE 4DSQC236T YB560103-CE 1

Introduction

The ABB DSQC236T YB560103‑CE Servo Drive Control Board is a precision‑engineered axis drive module developed for advanced motion applications within ABB robotic systems. Designed to control and coordinate servo motor movements with high fidelity, this board delivers dependable performance in environments where speed, accuracy, and repeatability are mission‑critical. Its robust design and seamless compatibility with ABB controllers make it an ideal choice for industrial robotics and automated motion control solutions.

Technical Specifications

SpecificationDetails
ModelDSQC236T YB560103‑CE
Module TypeServo Drive Control Board
PurposeAxis motion processing and servo control
System CompatibilityABB IRC5, S4C+, and select legacy robot control families
Power Supply24 V DC (provided by controller backplane)
Signal ConnectivityEncoder feedback inputs, motor control outputs
Communication InterfaceBackplane communication with CPU and network modules
Operating Temperature0 °C to +55 °C
Storage Temperature–40 °C to +70 °C
Humidity Tolerance5 %–95 % non‑condensing
Mounting LocationInternal controller rack slot
Dimensions (HxWxD)Approx. 250 mm × 24 mm × 240 mm
WeightApprox. 0.42 kg (0.93 lb)


Applications

This servo drive control board fulfills a wide array of motion control responsibilities in robotic and automated equipment environments:

  • Precision control of robot joint axes

  • High‑speed motion regulation in welding and machining robotics

  • Encoder feedback signal processing

  • Coordinated multi‑axis control for complex motion tasks

  • Replacement or service part in ABB controller maintenance

Whether applied in automotive assembly lines or packaging automation, the DSQC236T board enhances motion responsiveness and control accuracy.


Advantages

  • Accurate Motion Processing: Supports high‑resolution feedback loops for smooth motion control.

  • Robust Industrial Design: Built for consistent operation across a wide temperature and humidity range.

  • System Compatibility: Works with multiple ABB controller architectures for flexible deployment.

  • Compact Footprint: Slim form factor simplifies rack installation and panel design.

  • Reliable Interface: Designed to handle feedback and control signals with low latency.

  • Service‑Ready Component: Ideal replacement part for system upkeep and upgrades.

The combination of performance and dependability makes this board well suited for engineers and technicians working in production automation.


Technical FAQs (Frequently Asked Questions)

  1. What is the DSQC236T board used for?
    It provides servo axis control and feedback management for industrial robots.

  2. Which robot controllers is it compatible with?
    Commonly integrated in ABB IRC5, S4C+, and select legacy control systems.

  3. What power supply does it require?
    It runs on 24 V DC supplied through the controller backplane.

  4. Does it support encoder feedback?
    Yes, it processes encoder feedback for precise motion control.

  5. What is the typical operating temperature range?
    The board functions reliably between 0 °C and +55 °C.

  6. How heavy is the module?
    The board typically weighs about 0.42 kg (0.93 lb).

  7. Can it be used in multi‑axis systems?
    Yes — it works alongside other boards for coordinated multi‑axis motion.

  8. Is this board field replaceable?
    Qualified technicians can replace it during maintenance or service cycles.

  9. Does it require external cooling?
    Some controller configurations utilize internal forced‑air cooling, depending on system design.

  10. What environments are suitable for this board?
    It’s intended for standard industrial control cabinets and robot controller enclosures.
