Technical FAQs (Frequently Asked Questions)

1. What types of signals does this board support?
   The DSAX 110 supports both voltage (±10 V) and current (4-20 mA) analog signals.

2. How many channels are available?
   It provides 16 analog input channels and 12 analog output channels.

3. Is galvanic isolation provided?
   Yes, isolation is included to reduce noise and protect against ground loops.

4. What is the sampling rate per channel?
   Each channel can sample up to approximately 1 kS/s.

5. Can this board operate in high humidity environments?
   Yes, it is rated for 5% to 95% non-condensing humidity.

6. What is the operating temperature range?
   The board functions reliably between 0°C and 60°C.

7. Does this module require external power?
   It draws power from the host rack or controller backplane and typically consumes less than 5 W.

8. Can it be used in safety-critical systems?
   While the board is industrial-grade, safety system integration depends on overall system design and certification requirements.

9. What resolution does the analog conversion achieve?
   The analog conversion is 16-bit, enabling fine measurement granularity.

10. Is the module easy to replace in an existing system?
    Its standardized form factor makes field replacement and upgrades straightforward.
