ABB DATX130 3ASC25H214 Rotor Feedback Plate

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB DATX130 3ASC25H214 Rotor Feedback Plate

Name: ABB DATX130 3ASC25H214 Rotor Feedback Plate
Brand: ABB PLC
SKU: 3217
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:DATX130 3ASC25H214
Product Origin:Sweden
Product Dimensions:185 x 64 x 210mm
Product Weight:1kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Overview

The ABB DATX130 3ASC25H214 Rotor Feedback Plate is a precision‑engineered mechanical accessory designed to support reliable rotor position sensing and feedback in industrial automation systems. Serving as a stable mounting and reference surface for encoders and pulse feedback devices, this plate enhances measurement accuracy and repeatability — essential for motion control, speed monitoring, and advanced process automation. Built for industrial environments, the DATX130 combines rugged construction with precise alignment features.

Technical Specifications & Physical Details

Specification	Description
Manufacturer	ABB
Model Number	DATX130 (3ASC25H214)
Accessory Type	Rotor Feedback Plate
Function	Mechanical reference surface for rotary sensors
Compatible With	Incremental encoders, resolvers, and rotary pulse devices
Material	High‑strength industrial aluminum or steel
Mounting Style	Shaft, frame, or panel mount (application dependent)
Operating Temp	–20°C to +60°C
Environment	Industrial rated, vibration and shock resistant

Applications

This rotor feedback plate is ideal for systems where accurate rotational position or speed information is critical:

Supporting incremental encoders and resolver feedback devices
Motion control systems for motors and rotary equipment
Position measurement in conveyor, robotics, and packaging machinery
Speed and direction feedback for process automation loops
Industrial equipment requiring repeatable and reliable feedback data

Advantages

Stable reference surface: Ensures accurate rotor feedback alignment with minimal drift.
Industrial durability: Designed to withstand vibration, shock, and continuous operation.
Versatile compatibility: Works with a wide range of rotary sensors.
Easy installation: Standard mounting pattern simplifies field assembly.
Improved signal quality: Minimizes mechanical noise that can affect pulse counts.
Compact design: Integrates seamlessly within varied automation layouts.

Technical FAQs

What is the purpose of the DATX130 Feedback Plate?
It provides a stable reference surface for encoders or resolver feedback devices to improve measurement accuracy.
Which sensors can be used with this plate?
Incremental encoders, resolvers, and other rotary pulse feedback sensors.
How is it mounted?
It can be mounted to a shaft, frame, or panel depending on application requirements.
What material is used in its construction?
High‑strength aluminum or steel for industrial durability and precision.
What operating environments is it suited for?
Industrial settings with vibration, shock, and varying temperatures from –20°C to +60°C.
Does it help reduce signal noise?
Yes — by stabilizing the sensor mount and minimizing mechanical inconsistencies.
Is it compatible with high‑speed rotation?
Yes — designed for mechanical stability in high‑speed applications.
Does it require calibration?
Basic alignment during installation ensures optimal sensor feedback.
Can it be used outside ABB systems?
Yes — electrically and mechanically compatible with a wide range of standard rotary sensors.
Which industries benefit most from this accessory?
Manufacturing, robotics, packaging, automation, and process control environments.
